METAR TRAY
METAR TRAY
Cover Fixing Kits
Straight Tray Covers
The general method of assembly for the METAR cable tray cover is shown in the following image.
This method is common to both medium and heavy duty cable trays and to cable tray fittings.
Cable Tray Fitting Covers
METAR straight tray covers are 3m in length and are
available in widths of 50mm to 900mm as standard.
Covers are common for both closed and ventilated
applications.
METAR cable tray covers are supplied complete with all necessary fixing kits. Each fixing
kit comprises of a preformed mounting bracket, a corrosion resistant M6 spire nut, two
M6 screws and one M6 nut.
METAR cable tray fitting covers are available in widths
of 50mm to 900mm as standard. Covers are common for
both closed and ventilated applications.
Straight Cable Tray
Ventilated (Raised) Cover
Straight Cable Tray Closed
(Non-Ventilated) Cover
375
1475
Covers for straight cable tray and cable tray fittings
are supplied with the appropriate number of cover
fixing kits as follows:
Each cover fixing kit is supplied with the appropriate
cover mounting bracket for either a non-ventilated
cover or ventilated cover based on the part number
ordered. Dimensions for the cover mounting brackets
are as follows:
375
Straight Cable Tray Cover
Overall Dimensions &
Fixing Centres
Width
Tray & Fitting Type
Order details for all fittings except risers are as follows:
50mm to
150mm
200mm to
300mm
Straight Tray
6
6
90° Flat Elbows
3
4
60° Flat Elbows
3
4
45° Flat Elbows
3
3
30° Flat Elbows
3
4
4
3
3
4
4
Reducers
4
4
Wc
4
Equal Crosses
Order example:
Hb
4
Unequal Tees *
Omit the radius detail if the standard radius fitting is required.
4
Equal Tees
375
4
Outside Risers
Hc
3
Inside Risers
Tray Type / Cover Type / Tray Fitting Type / Width / (Radius) / Finish &
Material.
1.5
HR/CV/FE30/300/GA
35
Tray Width
mm
Bracket Height Hb mm
Height
Hc mm
Gauge
T mm
Weight
kg
50
Cover Type
Cover Width
Wc mm
61
11.9
0.9
2.51
75
86
11.9
0.9
3.17
Medium duty closed covers
25
28
100
111
11.9
0.9
3.92
Medium duty ventilated covers
53
150
161
11.9
0.9
5.43
Heavy duty closed covers
53
200
211
11.9
0.9
6.74
Heavy duty ventilated covers
78
225
236
11.9
0.9
7.70
300
* Stainless Steel and Silicon Rich Steel weight
conversion factors please refer to the Cable Tray
Technical Section.
Vantrunk Heavy Duty Return Flange Cable Tray
Ventilated Cover, 30° Flat Elbow, 300mm Wide,
c/w Cover Fixing Kits, Hot Dip Galvanized
Mild Steel.
311
12.2
0.9
9.96
Include the radius detail if a non-standard radius fitting is required.
Order example:
HR/CC/FE90/750/300/SS
Vantrunk Heavy Duty Return Flange Cable Tray
Closed Cover, 90° Flat Elbow, 750mm Wide,
300mm Radius, c/w Cover Fixing Kits, Stainless
Steel (316 Grade).
Covers for inside and outside riser fittings are supplied pre-formed to
angles of 30°, 45°, 60° or 90° to match the angle of the riser.
26
