METAR TRAY
METAR TRAY
Tray Earth Bonding Strap
Hold Down Bracket
The tray earth bonding strap for cable tray (EBS/05)
is designed for use in electrical installations where an
additional means of earthing or electrical bonding is
specified. The earth bonding strap comprises of a 4mm2
100mm long tinned copper braid with M6 tinned copper
end connectors. The earth bonding strap is suitable for
use with all types of METAR cable tray.
Hold-down brackets provide an
alternative means of securing cable
tray to the support structure, particularly
where the slots in the base of the cable tray do not
coincide with the supports. Ideal for use with Intelok
Channel type support systems, the hold-down bracket is
available for all cable tray profiles.
H
∅Ø11
Tray End Plate
Straight Tray Divider
METAR cable tray end plates provide an effective
termination for open ends of cable trays.
Straight tray dividers are available for cable segregation
and separation purposes along the length of the cable
run. Straight tray dividers are available to suit all cable
tray sections and are available in 3m lengths as standard.
Cable tray end plates are available in widths from 50mm
to 900mm as standard. Each end plate has 20mm x 7mm
fixing slots at 50mm centres which allow use for securing
the cable tray to a wall or floor.
METAR Cable
Tray Tray End
Plate used as
wall plate fixing
METAR Cable Tray
Tray End Plate used
to support tray at
wall aperture
40
40
METAR Cable Tray Tray
End Plate
T
F
H
W2
Earth bonding straps are not supplied with fixings.
Recommended fixings
– two M6 x 12 pan head screws and M6 nuts
(plus M6 flat washers for stainless steel).
Consult our Sales Team for details.
Part Number
L
H
Supplied with:
MTS/05
T
D
x0
C
Dimensions mm
Part
Number
= Select a Finish & Material
Tray
Width W
W2
50
MT/EP/100/
100
96
MT/EP/150/
A
Tray Type
Heavy Duty HR
W1
Dimensions mm
150
146
MT/EP/200/
H
A
B
C
D
52
23
40
W1 + 46
W1 + 80
Part Number
MT/HDB/
= Select a Finish & Material
21
B ¤
200
225
221
MT/EP/300/
300
296
= 50
1.0
Part Number
MT/DIV/SL3/
2
Dimensions mm
L
H
F
T
3000
47
20
1
= Select a Finish & Material
2
196
MT/EP/225/
Heavy Duty
T
No of
Fixing
Slots
1
46
MT/EP/50/
H
3
Heavy Duty
= 50
1.5
Straight tray dividers are not supplied with fixings (3 fixings required per
straight divider).
3
5
= Select a Finish & Material
Recommended fixings – M6 x 12 pan head screw and M6 nut (plus M6 flat
washer for stainless steel). Consult our Sales Team for details.
Subject to order requirements, straight tray dividers may be supplied in
1.5m lengths to suit delivery & shipping needs.
Tray end plates are not supplied with fixings.
Recommended fixings – M6 x 12 pan head screw and M6 nut (plus M6 flat
washer for stainless steel). Consult our Sales Team for details.
