METAR TRAY
METAR TRAY
Heavy Duty Adjustable Coupler
The METAR Heavy Duty Return Flange cable tray adjustable coupler allows horizontal
adjustment between adjacent lengths of cable tray.
Adjustable Couplers are supplied as pairs and with fixings.
ACCESSORIES
The METAR cable tray system is complemented by a range
of accessories deigned to aid installation and to add additional
functionality & flexibility to the cable tray installation.
Part Number
HR/AC/
= Select a Finish & Material
Where required the information shown is for Heavy Duty Return Flange accessories,
data for other sidewall heights is available on request.
Fish Plate Coupler
Lp
Wp
The METAR fish plate coupler gives
support across the base of the cable
tray and is available to suit cable
tray of widths 50mm to 900mm. Fish
plate couplers are recommended for
connecting straight cable trays which
are heavily loaded.
Part
Number
Tray Width
mm
Wp
mm
Lp
mm
T
Gauge
T mm
Heavy
Duty Return
Flange
Weight
kg
0.04
TR/FPC/50/
50
42
4
TR/FPC/75/
75
67
4
0.07
TR/FPC/100/
100
92
4
0.09
TR/FPC/150/
150
142
4
0.14
TR/FPC/200/
200
192
6
0.18
TR/FPC/225/
225
217
6
0.21
TR/FPC/300/
300
292
6
0.28
88
1.5
= Select a Finish & Material
