METAR TRAY
METAR TRAY
REDUCERS
Reducers are used to create a reduction in width along the cable
tray run.
Heavy Duty Intersections
Straight reducers (RS) are used to create a concentric reduction, having an equal
width reduction along both sides. Left hand reducers (RL) and right hand reducers (RR)
are used to create offset reductions to suit particular site installation requirements.
X
Left hand reducers have the width reduction on the left when viewed from the primary
width. Right hand reducers have the width reduction on the right when viewed from the
primary width.
Y
W1 W
The METAR Medium Duty Return Flange reducers have a sidewall height of 25mm.
The standard METAR Heavy Duty Return Flange reducers have a side wall height of
50mm. Other heavy duty side wall heights from 30mm to 150mm are available to order.
R
T
W
W1
Part
Number
Fitting
Width
mm
W
mm
W1
mm
T
mm
R
mm
X
mm
Y
mm
Weight
(kg)
MT/EC/50/
50
48.2
50
210
210
0.48
MT/EC/75/
75
73.2
75
235
235
0.62
MT/EC/100/
100
98.2
100
260
260
0.73
MT/EC/150/
150
148.2
150
310
310
0.98
MT/EC/200/
200
197.6
200
511
511
2.88
MT/EC/225/
225
222.6
225
536
536
3.17
MT/EC/300/
300
297.6
300
611
617
4.10
0.9
1.2
75
150
= Select a Finish & Material
Gauge & weights are given for the hot dip galvanized mild steel cable tray,
with a standard side wall height of 50mm. Refer to ‘Cable Tray Technical
Data’ for other materials and gauges.
H
METAR Heavy Duty Return
Flange Cable Tray Straight
Reducers
METAR Heavy Duty Return
Flange Cable Tray Left Hand
Reducers
METAR Heavy Duty Return Flange
Cable Tray Right Hand Reducers
Vantrunk cable tray reducers are available in any combination widths from
900mm to 450mm and from 450mm to 50mm as standard. Other width combinations
are available to order. The width is measured externally between the side walls to
facilitate the use of the integral coupler.
Vantrunk cable tray reducers have a standard length of 250mm.
Information shown is for Heavy Duty Return Flange reducers, data for other sidewall
heights available on request.
