Heavy Duty Equal Tees
METAR Heavy Duty Return Flange cable tray equal tees
have a main width Wim and a branch width Wb which are
identical.
CABLE TRAY TEES
X
Tees are used to create right angle intersections in the same plane,
between horizontal cable tray runs when the cable tray is installed in
the horizontal plane and between vertical cable tray runs when the cable
tray is installed in the vertical plane.
Wm1 Wm
Y
METAR heavy Duty Return Flange cable tray crosses are available in widths of
50mm to 900mm. The width is measured externally between the side walls to facilitate
the use of the integral coupler.
R
T
Wb
Wb1
The METAR Medium Duty Return Flange cross has a sidewall height of 25mm.
The standard METAR Heavy Duty Return Flange cross has a side wall height of 50mm.
Other heavy duty side wall heights from 30mm to 150mm are available to order.
H
METAR Medium Duty Return Flange crosses have a nominal internal radius of 75mm
for widths up to and including 150mm and a nominal internal radius of 150mm for
widths of 200mm and above. Other radii are available to order.
Information shown is for Heavy Duty Return Flange crosses, data for other sidewall
heights available on request.
Tray Fitting
Part
Number
Main
width
mm
Wm Wm1
mm mm
Branch
Width
mm
Wb
mm
Wb1
mm
T
mm
R
mm
X
mm
Y
mm
Weight
(kg)
MT/ET/50/
50
48.2
50
48.2
50
204
127
0.40
MT/ET/75/
75
73.2
75
73.2
75
229
152
0.52
MT/ET/100/
100
98.2
100
98.2
100
254
177
0.63
MT/ET/150/
150
148.2
150 148.2
150
304
227
0.87
MT/ET/200/
200
197.6
200 197.6
200
504
352
2.39
MT/ET/225/
225
222.6
225 222.6
225
530
377
2.61
MT/ET/300/
300
297.6
300 297.6
300
605
452
3.30
0.9
1.2
75
150
= Select a Finish & Material
