METAR TRAY
METAR TRAY
Heavy Duty 45° Flat Bends
X
FITTINGS
The METAR cable tray system comprises of a full range of
perforated cable tray fittings that provide changes in direction,
changes in width and to create intersections between straight
runs. METAR cable tray fittings feature an integral coupler.
Y
R
T
W
W1
The range of cable tray fittings includes flat bends, risers, equal & unequal tees, intersections
and reducers. Cable Tray fittings are available in all corresponding widths and Medium Duty
and all Heavy Duty sections.
Part
Number
Fitting
Width
mm
W
mm
W1
mm
T
mm
R
mm
X
mm
Y
mm
MT/FE45/50/
48.2
50
72
89
0.16
75
73.2
75
97
106
0.20
MT/FE45/100/
100
98.2
100
122
124
0.25
MT/FE45/150/
150
148.2
150
172
159
0.35
MT/FE45/200/
200
197.6
200
224
248
0.87
MT/FE45/225/
225
222.6
225
269
265
0.93
MT/FE45/300/
Flat Bends are used to create fixed angular changes in direction in
the same plane, between horizontal cable tray runs when the cable
tray is installed in the horizontal plane and between vertical cable
tray runs when the cable tray is installed in the vertical plane.
50
MT/FE45/75/
CABLE TRAY FLAT BENDS
H
Weight
kg
300
297.6
300
344
318
1.26
0.9
75
1.2
150
Gauge & weights are given for the hot dip galvanized mild steel
cable tray, with a standard side wall height of 50mm. Refer to
‘Cable Tray Technical Data’ for other materials and gauges.
Heavy Duty 90° Flat Bends
X
METAR cable tray flat bends are available in widths of 50mm to 900mm. The width is
measured externally between the side walls to facilitate the use of the integral coupler.
Y
The METAR Medium Duty Return Flange flat bends has a sidewall height of 25mm.
The standard METAR Heavy Duty Return Flange flat bends has a sidewall height of 50mm.
Other heavy duty sidewall heights from 30mm to 150mm are available to order.
R
METAR cable tray flat bends are available in fixed angles of 30°, 45°, 60° and 90° as standard.
METAR tray flat bends have a nominal internal radius of 75mm for widths up to and including
150mm and a nominal internal radius of 150mm for widths of 200mm and above. Other radii
are available to order.
T
W
W1
W
mm
W1
mm
50
48.2
50
MT/FE90/75/
75
73.2
75
MT/FE90/100/
100
98.2
100
MT/FE90/150/
150
148.2
150
MT/FE90/200/
200
197.6
200
MT/FE90/225/
225
222.6
225
MT/FE90/300/
Information shown is for Heavy Duty Return Flange flat bends, data for other sidewall
heights available on request.
Fitting
Width
mm
300
297.6
300
Part
Number
MT/FE90/50/
T
mm
150
Weight
kg
125
0.26
150
150
0.35
175
175
0.44
225
0.62
350
1.2
Y
mm
225
75
X
mm
125
0.9
R
mm
350
1.57
375
375
1.75
450
450
2.39
= Select a Finish & Material
