METAR cable tray is available in widths from 50mm, to 900mm. The width is measured
internally between the side walls.
METAR LENGTHS
METAR straight cable tray is available in standard lengths of 3m.
The METAR Cable Tray System is manufactured in two profiles
as standard based around two different side wall heights, each of
which gives the cable tray its specific load carrying capabilities.
The METAR Cable Tray features a slot pattern which is standard across the range of cable trays.
Based on a repeating pattern of 12mm by 8mm width wise slots and 20mm by 8mm length wise,
the METAR Cable Tray slot pattern suits cable ties, banding and cable cleats with M6 fixings.
See the Cable Tray Technical Section for details
METAR Medium Duty return flange cable tray is suitable for applications where medium duty
cable loads are to be supported over short to medium spans.
METAR Heavy Duty return flange cable tray is suitable for applications where heavy duty cable
loads are to be supported over longer spans.
Medium Duty Return Flange
Cable tray system has a side wall height
of 25mm.
Heavy Duty Return Flange
Cable tray system has a side wall height of
50mm as standard.
Part
Number
Tray Width
mm
W
mm
W1
mm
H
mm
MT/SL3/50/
50
50
51.8
2.48
MT/SL3/75/
75
75
76.8
3.00
MT/SL3/100/
100
100
101.8
3.52
MT/SL3/150/
150
150
151.8
MT/SL3/200/
200
200
201.8
MT/SL3/225/
225
225
226.8
MT/SL3/300/
300
300
302.4
Tray Width
mm
W
mm
W1
mm
MT/SL3/50/
50
50
51.8
MT/SL3/75/
75
75
76.8
MT/SL3/100/
100
100
101.8
MT/SL3/150/
150
150
151.8
MT/SL3/200/
200
200
202.4
MT/SL3/225/
225
225
227.4
25
T
mm
0.9
Weight
(kg)
H
T
4.56
W
5.60
W1
6.12
1.2
10.24
T
mm
Weight
kg
= Select a Finish & Material
Other sidewall
