Riser Divider
Cable Drop Out
End Plate
Earth Bonding Strap
Riser divider installed
on a Speedway 90°
Inside Riser
End plate shown
securing cable ladder to wall
(or floor for vertical installation)
METAR Riser Dividers (DIV/RL0.3) are available for
cable segregation and separation purposes on riser
fittings. The METAR Riser Divider is suitable for use
on inside and outside risers as well as the articulated
riser. METAR Riser Dividers are available in three
heights to suit METAR MT4, MT5, & MT6 Risers and
are 300mm in length.
METAR Cable Drop-Outs (CDO) are designed to provide a
smooth transition for cable, particularly those with a small
diameter, where these enter and leave the cable ladder.
Cable Drop-Outs are available to suit METAR Cable
Ladder of widths from 150mm to 1050mm as standard
and are common to all METAR Ladder types. Other
widths are available – contact our Sales Team for details.
Cable Drop-Outs are supplied with 2 fixing sets*
METAR Riser Dividers are supplied with 1 fixing set
per divider:
GA – M6x16 mushroom head bolt c/w short spring
channel nut
GA – M6x16 mushroom head bolt c/w short spring
channel nut
METAR End Plates (EP) provide a neat termination
for open ends of cable ladders.
METAR End Plates are available in widths from
150mm to 1050mm as standard. Other widths are
available – contact our Sales Team for details.
The METAR Earth Bonding Strap (EBS01) is designed
for use in installations where an additional means of
earthing or electrical bonding is specified.
Each METAR End Plate has 25mm x 11.5mm
fixing slots at 100mm centres which
allow the end plate to be used
for securing the cable ladder
to a wall or floor.
2
The METAR Earth Bonding Strap comprises of a 16mm
tinned copper braid crimped into M10 tinned copper end
connectors.
The METAR Earth Bonding Strap is common to
METAR MT4, MT5, & MT6.
SS – M6x16 pan head bolt c/w short spring channel nut and
flat washer.
Pre-punched holes for fixing the earth bonding strap are
located at each end of the ladder and fittings.
A
SS – M6x16 pan head bolt c/w short spring channel nut
and flat washer.
D
End plate shown closing
end of cable ladder run
B
W3
H
T
H
R
C
Dimensions (mm)
L
Dimensions (mm)
Part Number
Part Number
Ladder Type
MT4/DIVRL0.3/
130
280
430
Metar MT5
MT6/DIV/RL0.3/
Metar MT6
L
H
580
450
70
730
600
300
85
1
MT/CDO/900/
880
750
110
MT/CDO/1050/
1030
900
Hot Dip Galvanized Dividers are manufactured out of 1.2mm Gauge Material
MT/CDO/600/
120
60
150
172
2
300
322
3
MT /EP/450/
300
MT/CDO/750/
F
No. of
fixing
slots
W3
MT /EP/300/
150
*
H
Ladder
Width
MT /EP/150/
N/A
MT/CDO/450/
Dimensions (mm)
Metar MT4
MT5/DIV/RL0.3/
33
D
MT/CDO/150/
B
Part Number
C
MT/CDO/300/
T
A
450
472
5
MT /EP/600/
600
622
MT /EP/750/
750
772
MT /EP/900/
900
922
9
MT /EP/1050/
1050
1072
11
R
95
= Select a Ladder Type
SW4
& SW5
80
SW6
105
T
2
METAR Earth Bonding Strap as installed on a METAR Cable Ladder
6
8
= Select a Finish & Material
