METAR SUPPORT SYSTEMS
METALOK SUPPORT CHANNEL
QUICK GUIDE...
METAR SUPPORT SYSTEMS
METALOK SUPPORT CHANNEL
FLAT PLATE BRACKETS
Internal Washer
Designed to offer support and
mechanical strength to channels
on many different planes.
SHAPED & TOP HAT BRACKETS
6 Hole Straight Bar
7 Hole Straight Bar
BASE PLATES
A captive fixing bracket used to secure
channel side by side on the same plane
or channel on a horizontal plane to channel
on a vertical plane.
4 Hole Straight Bar
SUPPORT BRACKETS
Angled brackets come
in a range of angles to
provide reinforcement to
angular channel joints in a
framework.
3 Hole Straight Bar
90° Angled brackets allow
for right angle joints within
a channel framework.
ANGLE BRACKETS
2 Hole Straight Bar
90° ANGLE BRACKETS
Flat Plate Brackets provide joint
reinforcement between Steel Framing
Channel on the same or on different planes.
Square Washer
5 Hole Straight Bar
FLAT PLATE BRACKETS
Base Plates are to be used
for securing channel to the
floor or wall and will help to
distribute the concentrated
load over a larger area.
BEAM CLAMPS
Beam Clamps are designed to secure Steel Framing Intelok
Channel to secondary steelwork or building structures.
