Highlights the New 4TEX ® Drill and NOVI TECH™
Vibration Dampening Tooling System at IMTEX
Wohlhaupter India Pvt. Ltd.
Wohlhaupter India Pvt. Ltd. provides engineering, technical support, and onsite
application services within India for Wohlhaupter GmbH and Allied Machine and
Engineering Corp., leading manufacturers of holemaking and finishing tooling systems.
A
llied Machine and Wohlhaupter
GmbH devote their advanced
engineering
and
manufacturing
capabilities to creating the widest
selection of value-added tooling
available to metal-cutting industries
around the world. Allied Machine
&
Engineering’s
acquisition
of
Wohlhaupter GmbH in 2016 allows
Wohlhaupter India to expand their
product offering beyond precision
boring solutions. This partnership
empowers them to deliver the
lowest cost-per-hole in a wide
range of drilling, reaming,
burnishing,
and
threading
applications. As a result,
Wohlhaupter India is excited
to showcase two new cutting
tool innovations at IMTEX: the
NOVITECH vibration dampening
intermediate module system and
the 4TEX indexable insert drilling
system.
205mm (1.97” – 8.07”), with lengths up
to 10xD. The NOVITECH intermediate
modules
feature
Wohlhaupter’s
MultiBore system (MVS), making it
simple to use with existing Wohlhaupter
components
while
maintaining
compatibility with any machine spindle.
Achieve higher penetration rates than
standard twist drills for light duty
machines.
Wohlhaupter India will also feature the
Increase
boring
operations
productivity, surface quality, and
process reliability.
The
NOVITECH
vibration
dampened
intermediate
module is the newest addition
to the boring product line.
The NOVITECH increases boring
operations productivity, surface quality,
and process reliability while extending
the life of both the insert and the
machine center’s spindle. Mounted
inside the patented NOVITECH system,
the viscoelastically mounted damper
modules
reduce vibrations during the machining
of diameters ranging from 50mm –
27 | may-june 2019
new 4TEX indexable insert drill, ideal for
making shallow 2xD, 3xD, and 4xD holes
in the 12-47 mm (.472” – 1.850”) range.
Industries working with a variety of
materials – especially aerospace, heavy
equipment, automotive, and energy
industry applications – will benefit from
the excellent chip formation provided
by this drill’s unique geometries. It is
also an excellent choice for making
Keshav Khurana
interrupted cuts or drilling on angled
surfaces. The new design even enables
certain operations to be performed
without initial milling of the surface.
The 4TEX drill provides higher
penetration rates than standard twist
drills for light duty machines and is
also an excellent choice for making
interrupted cuts or drilling on angled
surfaces. The drill’s design provides
increased core strength resulting in
improved hole size and straightness.
Dual twisted coolant outlets
improve
penetration
rates
by enhancing coolant flow
and generating superior chip
formation and evacuation.
4TEX inserts are 4-sided to
maximize the tool life of each
insert. The distinctive insert shape
improves surface finish, hole
diameter, and hole straightness
by providing a superiorly balanced
cut compared to ISO inserts.
Insert geometries for standard
ISO material categories improve
hole quality and penetration
rate, while eliminating issues
from chips wrapping the tool.
They are available in geometries
developed for steel, stainless
steel, high temperature alloys, non-
ferrous, and iron, which are optimized
for excellent chip formation and wear
resistance in difficult applications. The
drills are stocked in both imperial and
metric shanks with standard fractional
diameters, as well as every ½ mm
diameter up to 26mm and every 1mm
up to 47mm assuring fast delivery.
www.wohlhaupterindia.in
