GHM edia B usiness Product Spotlight Small High Precision CNC lathe CNC 25 with Auto Bar feeder and live tool This CNC 25 is well established machine from Arrow range, this machine can be used for any Bar type parts from 3mm to 25mm, This machine will be having High speed spindle max 6000 rpm and with pneumatic Clamping system like Any Swiss Type CNC lathe. This machine will be having Slide with Ball screw and Linear guide ways fitted for X and Z axis with High Rapid 25m/min, This machine is well suitable for any auto parts with accuracy and high volume, This machine can be used for Bar parts or also for secondary parts by manual or Auto loading system. Machine size will be very much compact and these machines can be placed even in 1st/2nd floor, and this machine also consume less power and due to this advantage the parts can be produced from this can be cost effective in comparison of any CNC lathes. As we provide Long Parts Guide support system which be working with Guide bush like Swiss machine, so this machine can be easily replaced against Any High priced Sliding head CNC lathes. We can also fix the Live tooling with Drive and motor and C axis function for any Small Milling or drilling function either on Sideways or on face by changing easy brackets. This system avoid to change the job for costly VMC or any Drilling machines which always end with More labour and loosing accuracy . With the C axis functions many Indexing drillings can be done. In total customer can get the finished job from the bar, We can connect this machine with Automatic Bar loader 25mm dia up to 3mtrs length as additional attachment and also Part conveyor will be fixed so all finished part will be collected outside. This machine also can be connected with Auto loading for small and high volume forged parts. More than 150 machines working in India at many places for all Automobile parts manufactures .Many Automats/Big CNC can be avoided by this small compact machine thus saving cost, Less labour etc.info AUTO BARFEEDER MANUFATURING RANGE 1. SINGLE SPINDLE AUTOMATIC LATHE MODEL A-25,A-32,A-42,A-60 2. SECOND OPERATION LATHE MANUAL I AUTO CAPSTON SOL25/110, SOL32/110 3. SMALL ECONOMIC CNC LATHE CNC 20 / CNC 25 I MC 32. 4. ARROW FLATBED CNC LATHE AFL300I AFL400I WITH LINE ARITURRETI LIVE TOOLS. 5. SLANT BED CNC LATHE ASL6IASL8IASTL6 / ASTL8 6. XKC HIGH PRECISION CNC LATHE XKC20 /30I40FA 7. SWISS TYPE CNC LATHE JINNFAJSL20ABI32ABIBS205 8. ARROW TWIN SPINDLE CNC LATHE TS 32 26 | january-february 2019 | Global MDA 9. DMTG VERTICAL MACHINE CENTRE IVMCIVDL600I550/1000 10. JASU HIGH SPEED DRILLING ITAPPING CATER WITH PALLET CHAMPER 11. COMPLETE AUTOMATION SOLUTION 12. AUTOMATIC BAR FEED SFROMBARLOAD -TAIWAN 13. COLLET SI GUIDE BUSH FOR SWISS MACJINES. Global MDA Journal Journal
