EXTRA2 VAPORE
CALORIFIERS WITH 2 EXTRACTABLE HEAT EXCHANGERS FOR STEAM GENERATOR
APPLICATION
Production and storage of sanitary hot water. Suitable for steam
generators.
MATERIAL
Material and finishings, suitable drinkable water according to D. M. n.
174 dated 06.04.04,:
- Mild steel Polywarm® coated (certification ACS - SSICA - DVGW - W270
- UBA - WRAS)
HEAT EXCHANGER
2 stainless steel 316L straight heat exchangers suitable for steam power
INSULATION
NOFIRE® 50 mm soft polyester fibre 100% made of recyclable material,
with high Thermal insulation and Thermal conductivity: 0,039 W/mK.
Fire resistance class B-s2d0 according to EN 13501. PVC external lining
complete with top and flange cover.
CATHODE PROTECTION
n° 2 magnesium anodes with anoden tester
DRAIN
External confluence through drain pipe.
GASKET- FLANGE PLATE
Silicone gaskets suitable for alimentary use for max temperature up to
200°C. Flange plate.
WARRANTY
- 5 years (Polywarm®)
See general sales conditions and warranty
ACCESSORIES AND SPARE PARTS : See page 216
POLYWARM®
NOFIRE®
INSULATION
EXTRA 2 WXC VT VAPORE
Model
3000
4000
5000
HEAT EXCHANGER
HEAT EXCHANGER SURFACE
D.H.W. Storage: POLYWARM® coated
Heat Exchanger: STAINLESS STEEL
Art. Nr.
Price €
3069162363008
9.303,00
3069162363009
11.882,00
3069162363010
14.838,00
Lower
2
[m ]
3
4
5
Medio
[m2]
3
4
5
STAINLESS STEEL
316L
OK
STEAM HEAT EXCHANGERS TECHNICAL DATA
PED
Upper heat Exchangers peformances calculated with primary Upper heat Exchangers peformances calculated with primary
circuit at 6 bar saturated steam and production of DHW from circuit at 3 bar saturated steam and production of DHW from
10° to 45°C
10° to 45°C
HEAT
EXCHANGER
Model
MIDDLE
3000
4000
5000
Cat. I
Cat. I
Cat. I
[KW]
423
564
705
[l/h]
10393
13857
17321
LOWER
3000
4000
5000
Cat. I
Cat. I
Cat. I
423
564
705
10393
13857
17321
Output
DHW production
Ignition time
Output
DHW production
Ignition time
[l/10']
4098
5349
6907
[min]
11
11
11
[KW]
341
455
568
[l/h]
8378
11171
13963
[l/10']
3762
4902
6347
[min]
14
13
14
5438
7031
9097
17
17
17
341
455
568
8378
11171
13963
5102
6583
8537
22
21
22
Accessories on request
“Easy Control” Electronic Display
€
ART. NR.
5005000310002
420,00
Mounted and connected
Thermometer
Art. Nr.
5032240000107
5 units box
42
Titanium electronic anode
€
80,00
Art. Nr.
€
Model
5200000000013 607,00 3000÷5000
Suitable for
Polywarm®
coated models
