EXTRA2
CALORIFIERS WITH 2 EXTRACTABLE HEAT EXCHANGERS
APPLICATION
Production and storage of sanitary hot water
MATERIAL
Material and finishings, suitable drinkable water according to D. M. n.
174 dated 06.04.04,:
- Mild steel Polywarm® coated (certification ACS - SSICA - DVGW - W270
- UBA - WRAS)
HEAT EXCHANGER
2 heat exchangers, (upper: straight - lower: Antilegionella® with tubes
bent to the bottom - available on stainless steel 316L or copper
INSULATION
NOFIRE® 50 mm soft polyester fibre 100% made of recyclable material,
with high Thermal insulation and Thermal conductivity: 0,039 W/mK.
Fire resistance class B-s2d0 according to EN 13501. PVC external lining
complete with top and flange cover.

CATHODE PROTECTION
Magnesium anode with Anoden Tester (Polywarm®) Models > 1500 n° 2
magnesium anodes.
DRAIN
External confluence through drain connection.
Models > lt 1000 external confluence through drain pipe.
GASKET- FLANGE PLATE
Silicone gaskets suitable for alimentary use for max temperature up to
200°C. Flange plate.
WARRANTY
- 5 years (Polywarm®)
See general sales conditions and warranty
ACCESSORIES AND SPARE PARTS : See page 216

HEAT EXCHANGER SURFACE

EXTRA 2 WXC VT
®

PROMPT DELIVERY

POLYWARM®

ANTILEGIONELLA®
HEAT EXCHANGER

NOFIRE®
INSULATION

Model

1-5 days to dispatch
(delivery time excluded)

200
300
500
800
1000
1500
2000
2500
3000
4000
5000

HEAT EXCHANGER

D.H.W. Storage: POLYWARM coated
Heat Exchanger: STAINLESS STEEL
Art. Nr.
Price €
3082162360101
1.699,00
3082162360102
1.872,00
3082162360103
2.372,00
3082162360104
3.324,00
3082162360105
3.668,00
3082162360106
4.768,00
3082162360107
6.397,00
3082162360113
7.604,00
3082162360108
8.025,00
3082162360110
10.187,00
3082162360112
11.783,00

Lower

Upper

[m2]
0,5
0,75
1,5
2
3
3
4
5
6
8
10

[m2]
0,5
0,75
1,5
2
2
3
4
5
6
8
10

STAINLESS STEEL

316L

OK

HEAT EXCHANGER SURFACE

EXTRA 2 WRC VT
Model

POLYWARM®

200
300
500
800
1000
1500
2000
2500
3000
4000
5000

D.H.W. Storage: POLYWARM® coated
Heat Exchanger: COPPER
Art. Nr.
Price €
3082162350101
1.735,00
3082162350102
1.945,00
3082162350103
2.601,00
3082162350104
3.568,00
3082162350105
3.969,00
3082162350106
4.922,00
3082162350107
6.751,00
3082162350113
8.307,00
3082162350108
8.980,00
3082162350110
11.236,00
3082162350112
13.346,00

Lower

Upper

[m2]
0,5
0,75
1,5
2
3
3
4
5
6
8
10

[m2]
0,5
0,75
1,5
2
2
3
4
5
6
8
10

Accessories on request
“Easy Control” Electronic Display
€
ART. NR.
5005000310002
420,00
Mounted and connected

Thermometer
Art. Nr.
5032240000107
5 units box

Electrical immersions kit available

Titanium electronic anode
€
80,00

Art. Nr.
5200000000008
5200000000009
5200000000011
5200000000013

€

Model

220,00 200, 300
274,00 500, 800
335,00 1000, 1500
607,00 2000÷5000

Suitable for
Polywarm®
coated models

MONOPHASE
THREEPHASE
4 kW
5 kW
6 kW
9 kW
12 kW
1,5 kW
2 kW
3 kW
Quantity of water
affected by the 5240000000034 5240000000035 5240000000036 5240000000027 5240000000028 5240000000029 5240000000030 5240000000031
Mod. electric heater
€ 358,00
€ 358,00
€ 359,00
€ 361,00
€ 481,00
€ 254,00
€ 254,00
€ 256,00
[lt]
Ignition time from 10 °C to 45 °C with immersion heaters [min]
49
87
65
44
200
141
//
//
//
//
76
136
102
68
212
41
//
//
//
300
127
228
171
114
353
68
57
//
//
500
178
318
239
159
565
95
80
53
//
800
243
436
327
218
163
131
109
73
54
1000
288
516
387
258
194
155
129
86
65
1500
443
793
595
396
297
238
198
132
99
2000
577
1033
775
517
387
310
258
172
129
2500
577
1033
775
517
387
310
258
172
129
3000
797
1428
1071
714
535
428
357
238
178
4000
699
559
466
311
233
1040
1864
1398
932
5000
