EXAMPLE OF INSTALLATION
INSTALLATION WITH ECO COMBI 3
A
Sanitary water inlet
B
Domestic hot water user
C
Heating system
1
Buffer tank Eco Combi 3
2
Gas/Gasoil burner
3
Biomass Boiler
4
Opened expansion vessel
5
Circulation group
6
Hydraulic safety group
7
Solar panels
8
Solar system circulation group
7
4
8
3
5
C
5
1
5
2
5
5
B
6
TECHNICAL SUPPORT
A
The following schemes are purely illustrative. To realize the installation, always refer to a qualified design engineer.
