ACCESSORIES AND SPARE PARTS (CALORIFIERS - BUFFER TANKS)
COPPER FINNED AND TINNED HEAT EXCHANGERS (AVAILABLE ON EXTRA PLUS - INERTIAL TANKS)
Including flangeplate, gaskets, bolts and user manual.
Df
P
P
Heat Exchanger
Surface
COPPER FINNED
AND TINNED COIL
Price [€]
[m2]
0,76
0,94
1,58
2,27
2,63
3,17
4,54
5,26
6,34
Art. Nr.
5221000061003
5221000061002
5221000061004
5221000061021
5221000061022
5221000061023
5221000061024
5221000061025
5221000061026
424,00
453,00
667,00
858,00
960,00
1.048,00
1.515,00
1.657,00
1.931,00
De
142
142
170
170
190
190
190
190
190
Flange plate Ø
Df
[mm]
300
300
300
300
300
300
300
300
300
L
P
[Gas]
400
1”
410
1”
440
1”
570
1”
570
1”
665
1”
750 1” 1/4
850 1” 1/4
980 1” 1/4
Capacity
[liters]
0,60
0,54
1,21
1,79
2,07
2,51
3,60
4,14
5,10
ADDITIONAL COPPER FINNED COIL (FOR 800 AND 1000 LITERS BOLLY® ST 1 - 2)
Art. Nr.
3/4”
3/4”
Descrizione
Price [€]
5221000910001
Sup.=0,94m2 - De=145 mm - L=370 mm
384,00
COPPER finned coil for Bolly FIT 1 - 2 ≥ 800 lt, including
flange plate (Ø 240 mm), gaskets, bolts and user manual.
FLANGE PLATE FOR “EXTRA 1,2,3” CALORIFIERS AND ACCUMULATION TANKS
The Flange plate includes 2 sleeve collars for the connection to the operating
system. This allows the circulation of the liquid within the heat exchanger’s
serpentine doing the real separation between the incoming liquid and the
outgoing one. The flange plate is in mild steel. Blind flange for accumulation
tank in Polywarm® available also with 1 connection. Including: gaskets, bolts
and bushes
Art. Nr.
Price [€] Connections
5206000000001 149,00
1"
5206000000002 200,00
2"
5206000000003 221,00
2"
Includes 2 gaskets, bolts and bushes
Version for pipes heat exchanger
Diameter [mm]
300
380
430
FLANGE PLATE FOR INERTIAL TANKS
Art. Nr.
Price [€] Connections Diameter [mm]
5206000000051 146,00
1" 1/2
300
Includes 1 gasket and bolts
1 connection for electrical immersion (available on
accumulation tanks)
GASKET FOR FLANGE PLATE
Art. Nr.
Price [€]
Diameter [mm]
5206000000101
300
115,00
5206000000102
380
147,00
5206000000103 172,00
430
Includes 1 gasket and bolts
Blind flange available (available on accumulation
tanks)
The function of the EPDM gasket is to connect between them components and extractible heat exchanger. Sold by pair, this includes the gasket with crosspiece which is placed
between the flange plate and the heat exchanger’s plate. The gasket without crosspiece is placed between heat exchanger’s plate and the boiler’s flange.
Pair of gasket for boilers EXTRA 1,2,3 - includes bolts and bushes.
Pair of gasket for boilers EXTRA VAPORE - includes bolts and bushes.
Art. Nr.
Price [€] Diameter [mm]
5021220401001
300
88,00
5021220401002
380
115,00
5021220401003
430
123,00
One gasket with crosspiece and one without.
Silicone gaskets suitable for alimentary use for max temperature up to 200°C. (D.M.
n.174 dated 2004 - see certifications page).
Art. Nr.
Price [€] Diameter [mm]
5021220460111
300
88,00
5021220460112
380
115,00
5021220460113
430
123,00
One gasket with crosspiece and one without.
Made in material for max. temperature up to 192°C
SELECTION OF THE FLANGE PLATE AND GASKET FOR “EXTRA 1,2,3” CALORIFIERS
Flange plate
diameter
[mm]
300
380
430
Extra 1 e Vasi Inerziali
LOWER heat exchanger
from 200 to 500
from 800 to 1500
from 2000 to 5000
Extra 2
Extra 3
LOWER heat exchanger UPPER heat exchanger LOWER heat exchanger MIDDLE heat exchanger UPPER heat exchanger
Model
from 200 to 500
from 200 to 500
from 200 to 500
from 200 to 500
from 200 to 500
from 800 to 1500
from 800 to 1500
from 800 to 1500
from 800 to 1500
from 800 to 1500
from 2000 to 5000
from 2000 to 5000
from 2000 to 5000
from 2000 to 5000
from 2000 to 5000
FLANGE WITH CONNECTION FOR ELECTRICAL IMMERSION ( BOLLY® 1 - BOLLY® 2 POLYWARM®)
Description
Price [€] FLANGE WITH CONNECTION FOR
ELECTRICAL IMMERSION
1” 1/2 Flange ø 190 mm- With Connection For Electrical Immersion + Flange Plate Gasket
5212000910017
81,00 Included gaskets, bolts and user manual.
®
(Bolly 150÷500)
2” Flange ø 190 mm- With Connection For Electrical Immersion + Flange Plate Gasket
5212000910018
84,00
(Bolly ® 150÷500)
1” 1/2 Flange ø 240 mm- With Connection For Electrical Immersion + Flange Plate Gasket
5212000910020
110,00
(Bolly ® 800÷1000)
