VASO A MEMBRANA ZINCATO PED VT
VERTICAL GALVANIZED DIAPHRAGMS EXPANSION VESSEL WITH MEMBRANE (DIR. 97/23/CE-P.E.D.)
PROMPT DELIVERY
Model
VASO MEMB. Z PED VT
Price
Art. Nr.
3911161991007
3911161991008
3911161991003
3911161991004
3911161991005
3911161991006
[€]
134,00
183,00
195,00
480,00
774,00
1.101,00
1-5 days to dispatch
(delivery time excluded)
50
80
100
200
300
500
PRESSURE
TEMPERATURE
Pmax
10 bar
Tmax
[see table]
TECHNICAL DESCRIPTIONS
Vertical Z PED Diaphragms expansion vessels with
membrane are used for lifted water system and
they represent a pressurised water lung that, if duly
dimensioned , reduces pump cycling.
The peculiarity of this product is the physic separation
between water and air made by the diaphragms.
MATERIAL
Galvanized mild steel
- pressurized fluid: water+air or nitrogen
- Fluid group: 2
- max. working pressure: 10bar
DIAPHRAGMS
Elastic EPDM foodstuff membrane suitable for drinking
water.
DOCUMENTS ATTACHED
• CE Certificate
• User Instructions
APPLICATION
Perfect to ensure water deliveries to the top floors of
the building or to work in case of insufficient water
supplied by waterworks, or to stabilize pressure in the
domestic water supply by absorbing expansion when
the water is heated.
De
CERTIFICATIONS
Z PED VT Diaphragms expansion vessels with
membrane are preduced in accordance with safety
disposal of European Directive 97/23/CE (P.E.D.) in
terms of pressurized.
They are CE labelled with design data:
WARRANTY
2 years - See general sales terms and conditions.
(1)
Model
H1
H
50
80
100
200
300
500
De
H
H1
400
450
450
550
650
750
[mm]
627
717
872
1187
1254
1511
91
88
88
151
150
144
1
2
CONNECTIONS Gas
1” M
Air inlet valve
1” M
1/2”
1” M
Water
1/2” Instrumenta- 1” 1/4 F in/out
tion
1/2”
1” 1/4 F
1/2”
1” 1/4 F
Temp.
min/max
°C
-10/+99
-10/+99
-10/+99
Air inlet -10/+99
valve
0/+50
0/+50
3
(3)
(2)
VASO A MEMBRANA ZINCATO PED 24 LT
GALVANIZED EXPANSION VESSEL WITH MEMBRANE (DIR. 97/23/CE-P.E.D.)
350
355
WORKING
PRESSURE
Pmax
8 bar
OPERATING
TEMPERATURE
Tmax
-10/+99 °C
Model
VASO MEMB. Z PED
24 LT
Price
24
Art. Nr.
3901190600001
[€]
62,00
206
1”
Gas M
