VOLANO TERMICO CALDO-FREDDO R/C GB VT
VERTICAL INERTIAL HOT/COLD WATER TANK BOX
PRESSURE
TEMPERATURE
Pmax
6 bar
Tmax
-10 / +90 °C
TECHNICAL DESCRIPTIONS
These buffer are with hard box insulation and an
external lining with a galvanized and painted plate, raw
inside. They are suited for installation that works with
cold water during Summer and hot water during Winter.
They also allow to limit the number of switch on/off
of the generator (either heat pump, chilled system or
standard burner) increasing the thermic inertia of the
system and to have more fixed temperatures.
MATERIAL
Made in mild steel outside painted. There is no need
of any anti-corrosion treatment due to the fact that the
buffer is in a closed circuit without any adding air.
APPLICATION
Storage of chilled or hot water for inverter installations.
EXTERNAL COVER
Galvanized and painted metallic cover from 100 to 2000
litres
PVC plastic color grey from 3000 to 5000 litres
CORROSION PROOF TREATMENT
Not needed as the tank as to be connected to a closed
system, without any further air admission.
INSULATION
Polyurethan Hard foam (lambda 0.023 W/mK), without
CFC. Minimal thickness 30mm.
WARRANTY
2 years - See general sales conditions and warranty.
PROMPT DELIVERY
1-5 days to dispatch
(delivery time excluded)
Model
100
200
300
500
800
1000
1500
2000
ACQ. R/C. GB VT
(HARD BOX INSULATION)
€
Art. Nr.
3001162310501
364,00
3001162310502
463,00
3001162310503
602,00
3001162310504
784,00
3001162310505
1.141,00
3001162310506
1.411,00
3001162310507
1.924,00
3001162310508
2.287,00
SUITABLE FOR OUTSIDE INSTALLATION
198
