VOLANO TERMICO PDC
ENERGY BUFFER FOR HEAT PUMP
PRESSURE
TEMPERATURE
Pmax
4 bar
Tmax
-10 / +95 °C
TECHNICAL DESCRIPTIONS
Buffer either for hot or cold water provided by heat
pump, in order to limit the switch on/off of the generator.
MATERIAL
Made in mild steel outside painted. There is no need
of any anti-corrosion treatment due to the fact that the
buffer is in a closed circuit without any adding air.
EXTERNAL LINING
PVC plastic grey
INSULATION
Polyurethan Hard foam (lambda 0.023 W/mK), without
CFC. Minimal thickness 30mm.
Surfaces are treated with a special stain-remover that
makes easier the removal of the insulation at the end of
the technical life of the product.
WARRANTY
2 years
See general sales terms and conditions
De
Df
(10)
PROMPT DELIVERY
1-5 days to dispatch
(delivery time excluded)
100
200
300
500
H6 (7) (8) (9)
H5 (6)
1-2
H4 (5)
ENERGY BUFFER
FOR HEAT PUMP PDC
€
Art. Nr.
3001162311001
386,00
3001162311002
467,00
3001162311003
570,00
3001162311004
770,00
Model
3
4-5
From the heat Pump
Connexion for Electrical Immersion 1”1/2 Gas F
To the System
6
8
H1 (1) (2)
To the System
Connection for instrumentation 1/2” Gas F
9
H2 (3)
Connection for instrumentation 1/2” Gas F
7
H3 (4)
To the System
10
Model
100
Weight
De
Df
H
H1
[Kg]
35
H2
H3
To the System 1"¼ Gas F
H4
H5
mm
461
400
990
206
H6
1-2-4-5-7-9
Connections Gas F
246
374
543
511
711
1”
200
60
517
450
1289
206
246
489
793
836
1086
1”
300
80
624
550
1346
256
276
536
816
846
1096
1” ¼
500
100
724
650
1626
271
291
634
998
1091
1361
1” ¼
