PLATE HEAT EXCHANGERS
RANGE
PHC Plate to plate Exchangers range is composed
by 4 sizes, each one combined with innumerable
number of plates, giving suitable solutions to
several application of the HVAC industriy.
In particular PHC 3120 plate allows an output from
43kw to 370kw with high delta T (80°C primary
circuit and 10°C to 45°C on the secondary). With
similar energy request but different and lower delta
T, the PHC 4620 and PHC 7420 shall be selected.
For big output request version PHC 7431 is
recommended.
The following tables shall be considered as merely
indicative tool, for an optimized designing of Heat
echanger Dimesion, our technical department will
support you on every request.
MATERIAL
• Frame (not in contact with fluids) in painted mild
steel
• Guide for Heat exchanger plates, bolts and screw
nuts (not in contact with fluids) in galvanized mild
steel
• Nipples and plates (in contact with fluid) in 316L
Stainless Steel
• EPDM Gaskets
MAXIMUM OPERATING CONDITIONS
Max. Pressure= 10bar
Max. Temperature= 140°C (to be intended as max working temperature of gaskets).
Pressure not exceeding 0.5 bar above normal atmospheric pressure.
CHEMICAL COMPATIBILITY
Material used for PHC Exchangers are suitable for following liquids:
• Water
• Milk
• Whisky
• Acetone
• Glycole
• Glycoled Water
• Mineral Water
• Wine
• Wine Vinegar
• Etanol
• Etilenic Glycole
• De-mineralized Water
• Acetic Acid
• Beer
• Liquors
• Methanol
• Propylenic Glyco
Movable plate
Gaskets
Upper plate guide
APPLICATION
PHC Heat exchangers are used in domestic and industrial installation. In particular
they’re suitable for production of D.H.W., as well as for heating of swimming pools
using different energy sources (traditional boiler, solid fuel, solar thermal system). For
domestic application, the PHC are suitable for district heating installation.
Starting plate
Connections
TECHNICAL INFORMATION
PHC exchangers are inspectionable plate to plate type. Their shape ensures the
possibility of open the exchanger for cleaning.
The modular design allows you to change the configuration of the exchanger even after
a period of use (within certain limits).
PHC exchangers are designed for the use stated on Art. 3.3 of PED 97/23/CE.. In
particular, they are intended to be used with non-dangerous liquids with steam pressure
at maximum operating temperature not exceeding 0.5 bar above normal atmospheric
pressure.
Every Exchanger has serial number label and end-user manual.
End plate
Plate groupe
Bolt
Fixed plate
Lower plate guide
Connections
PROMPT DELIVERY
EXCHANGERS PHC 3120
69
1
N°
of
PLATES
3
Art. Nr.
(1-5 days to dispatch-delivery time excluded)
Price [€]
S Fixing
quote
L
Primary Vol.
= Secondary Vol.
Output (*)
Primary Secondary
Primary Secondary
Pressure Pressure
Flow rate Flow rate
loss
loss
231
310
[m3/h]
[m.c.a.]
[m.c.a.]
[mm]
[mm]
[lt ]
[Kcal/h] [KW]
[m3/h]
9
3175056650009 545,00
27
0,20
36973
43
1,89
1,06
1,42
0,60
11
3175056650011 590,00
33
0,25
49871
58
2,55
1,44
1,64
0,69
13
3175056650013 635,00
39
0,30
65348
76
3,35
1,88
1,92
0,81
15
3175056650015 680,00
45
0,35
74807
87
3,83
2,15
1,85
0,79
2
4
17
3175056650017 725,00
51
0,40
93723
109
4,80
2,70
2,19
0,93
19
