HEATING WATER BUFFER TANK WITH MACS® MODULE FOR IMMEDIATE D.H.W. PRODUCTION Tmax 99 °C Pmax 6 bar Tmax 99 °C F max 30 °f De Df (19) MODULE Pmax 3 bar DHW HARDNESS MACS® STAINLESS STEEL PLATE HEAT EXCHANGER (MACS®) STORAGE H13 (16) (17) (18) H11 (14) H10 (12) (13) H9(11) 1-2-6-7 H7 (9) Heating return/To Generator 1”1/2 Gas F 4-5 Connection for instrumentation 1/2” Gas F 9 Electrical immersion resistance 1”1/2 Gas F 11 Connection for instrumentation 1/2” Gas F H5 (6) (7) H4 (5) 12-1316-18 Heating delivery/From Generator 1”1/2 Gas F 14 - 17 H3 (4) H1 (1)(2) Connection for instrumentation 1/2” Gas F 0 19 20 (1) (6) (12) (16) Domestic cold water circuit inlet 1” Gas M (3/4” for models from 500 to 1500) 21 (19) Heating delivery 1”1/2 Gas F Domestic hot water circuit outlet 1” Gas M (3/4” for models from 500 to 1500) (2) (7) (9) (13) (18) (4)(5)(11) 50° (14)(17) 50° (20) (21) P.E.D. product planned and produced in conformity to the article 3.3 of directive 92/23/CE Model 500 600 800 1000 1500 Df De H A H1 H3 H4 H5 H7 H9 H10 H11 H13 360 360 378 384 432 533 582 584 656 736 629 695 690 787 845 870 970 918 1145 1236 1025 1200 1115 1388 1396 1011 1144 1115 1309 1377 1130 1485 1442 1588 1783 1343 1593 1541 1831 1909 [mm] 650 650 790 790 950 850 850 990 990 1150 1619 1870 1840 2130 2250 1666 1915 1895 2180 2315 247 247 265 265 313 D.H.W. PRODUCTION AND EASY STRATIFICATION WITH LABYRINTH SPREADER (CORDIVARI PATENT) The MACS® station is connected to the Buffer Tank, thanks to a circulator, the heating water is moved to the stainless steel plate exchanger for immediate production of D.H.W. Performances are optimized with the “Labyrinth Spreader” (Cordivari Patent) [Fig 1] that thanks to its spread shape allows a perfect stratification of the water that returns back from the MACS® module, and avoid any turbolences that would effect thermal stratification inside the buffer tank: Fig. 1 - Labyrinth Spreader (Cordivari Patent) thermography Fig. 2 - Normal buffer stratification thermography 163 MULTIFUEL ENERGY H P.E.D. product planned and produced in conformity to the article 3.3 of directive 92/23/CE PUFFERMAS®
