ECO-COMBI - OUTPUT AND PERFORMANCES
D.H.W. STORAGE PERFORMANCES
COMPLETE HEATED STORAGE VOLUME
Model
UPPER PART HEATED STORAGE VOLUME
Max sanitary water
Max sanitary water
Max sanitary water produced
Max sanitary water produced
DHW DHW exchanger
produced from 10°C to 45°C
produced from 10°C to 45°C
from 10°C to 45°C with storage
from 10°C to 45°C with storage
Volume
surface
with storage at 65°C and
with storage at 65°C and
at 65°C and boiler on
at 65°C and boiler on
boiler off
boiler off
[liters]
[m2]
[lt/min]
500
26,6
4,5
29
600
31
5,3
34
800
33,4
5,8
[liters]
[lt/min]
10 lt/min: 354 lt
25 lt/min: 227 lt
10 lt/min: 400 lt
25 lt/min: 257 lt
10 lt/min: 587 lt
25 lt/min: 377 lt
37
[liters]
10 lt/min: 102 lt
25 lt/min: 75 lt
10 lt/min: 115 lt
25 lt/min: 85 lt
10 lt/min: 218 lt
25 lt/min: 160 lt
15
18
23
ECO COMBI 2 - ECO COMBI 3 LOWER FIXED HEAT EXCHANGERS POWERS CHART
Output of the EcoCombi 2 - EcoCombi 3 lower heat exchangers
depending on the average DeltaT between primary and
accumulation considering fl ow rate 3 m 3 /h.
140
120000
120
100000
80000
2000 LT
80
60
1500 LT
1250 LT
1000 LT
40
800 LT
600 LT
60000
40000
Potenza [KCal/h]
Output [KCal/h]
100
Potenza [KW]
Output [KW]
Thermal output is given in both KW or kcal/h in terms of average
temperature difference between primary and secondary circuit, all
for a range of primary 3 m3/h.
For example, a 1000 liters ECOCOMBI 2 with a water flow of 3 m3/h
at 80 °C inlet and outlet at 70 °C, has on the storage of water an
average temperature of 60 °C, the mean difference of temperature
will be:
(80 +70) / 20-60 = 15 °C and therefore you can exchange up to
approximately 32 KW.
500 LT
20000
20
0
0
0
5
10
15
20
25
30
35
Delta T medio [°C]
Average Delta [°C]
ECO COMBI 3 UPPER FIXED HEAT EXCHANGERS POWERS CHART
Output of the EcoCombi 3 upper heat exchangers depending
on the average DeltaT between primary and accumulation
considering fl ow rate 3 m 3 /h.
60
50000
1500-2000
50
1000-1250
40000
800
30000
30
500-600
20000
20
10000
10
0
0
0
5
10
15
20
Average Delta [°C]
158
25
30
35
Output [KCal/h]
Output [KW]
40
