DOUBLE WALLED TANK IN TANK CALORIFIERS SUITABLE FOR SOLAR THERMAL SYSTEMS
STORAGE
Pmax
Tmax
6 bar
90 °C
6 bar
POLYWARM®
INOX 316L
HEAT EXCHANGERS
Pmax
Tmax
2,5 bar
99 °C
2,5 bar
95 °C
BOLLY® - INTERKA
FINISHING
99 °C
L
1
Domestic Cold Water Circuit Inlet 3/4" Gas F
Ø450
Magnesium anode
8
L2 (4)
Electrical immersion resistance (optional)
Instrumentation 1/2" GAS F
9
L1 (2)(3)
Domestic hot water circuit outlet 3/4" Gas F
6
7
0
Solar collector connection 3/4" Gas F
5
(1)(5)
Purge volume 1/2" Gas F
4
(6*)(7)
(8)(9)
Solar collector connection 3/4" Gas F
3
Ø550
2
Instrumentation 1/2" GAS F
(3)
15°
P.E.D. product planned and produced in conformity to the article 3.3 of directive 92/23/CE
H2(5)
H1(1)
0
(2)(4)
45°
P.E.D. product planned and produced in conformity to the article 3.3 of directive 92/23/CE
INTERKA SOLARE
In Solar Thermal Systems the use of a combined TP valve
(Temperature and Pressure) is recommended.
Model
Weight
L
L1
L2
[kg]
H1
H2
[mm]
150
58
1227
343
783
88
100
200
72
1487
353
1043
88
100
300
109
2172
343
1723
88
100
107
