BOLLYTERM® HPI SOLARE
POLYWARM® COATED CALORIFIERS WITH INTEGRATED HEAT PUMP AND 1 FIXED HEAT EXCHANGERS SUITABLE FOR SOLAR THERMAL SYSTEMS
APPLICATION
Production and storage of sanitary hot water
MATERIAL
Material and finishings, suitable drinkable water according to D. M. n.
174 dated 06.04.04,:
- Mild steel Polywarm® coated (certification ACS - SSICA - DVGW - W270
- UBA - WRAS)
HEAT EXCHANGER
The thermal exchange is ensured by:
- integrated heat pump
- “plug&play” electrical immersion resistance - 1500 Watt
- 1 Polywarm® coated fixed heat exchanger
INSULATION
Ecological hard polyurethane foam, thickness 45 mm with high thermal
insulation and thermal conductivity 0,023 W/mK.
PVC external lining complete with ABS top and flange cover.
HEAT PUMP
Integrated heat pump - C.O.P. 2,95 According to en 16147 insulated
compressor with ecological coolant r134a
CATHODE PROTECTION
Magnesium anode with Anoden Tester
DRAIN
External confluence through drain connection.
GASKET- FLANGE PLATE
Silicone gaskets suitable for alimentary use for max temperature up to
200°C. Flange plate.
WARRANTY
- 5 years (Polywarm®)
See general sales conditions and warranty for electrical parts
ACCESSORIES AND SPARE PARTS : See page 216
Heat exchanger
surface
BOLLYTERM® HPI SOLARE
Model
300
Model
Room
Average electrical
Heat Pump
temperature
power absorbed
thermal output C.O.P.
min/max
by the Heat Pump
[°C]
[W]
[W]
Net volume heated
from heat pump
[liters]
165
300
D.H.W. Storage: POLYWARM® coated
Heat exchanger POLYWARM® coated
Art. Nr.
Price €
3181162330123
2.728,00
-5 / +44
2020
4,16
486
Ignition time
[min]
228’
[m2]
1,2
Electrical
Suggested
integration solar collectors
power
surface
[W]
[m2]
1500
6
Data obtained under the following conditions (T air 20 °C - T water from 15 °C to 55 °C)
INTEGRATED HEAT PUMP
Bollyterm is 2,95(*).
The C.O.P on the Bollyterm® HP Cordivari is 2,95(*) and allows to heat the water in
an ecological, economical and easy way.
Besides, the Bollytherm HP is already equipped as standard with a 1500 watt
electrical immersion heater to help the thermodynamic working in some situation.
• C.O.P. 2,95 according to EN 16147 (T air 20 °C T water 48,5 °C)
• Insulated compressor with ecological coolant R134A
• Heat pump condensator coil external to the tank avoiding any contact Gas-domestic
hot water
• Radial fan
COMPRESSOR
• Electronic control display
Power
supply
Max water
temperature
[V / Ph / Hz]
[°C]
220-240 / 1 / 50
60
Coolant
Pressure
Acoustic
level
[tipo]
[g]
850
46
C.O.P.
Inlet and
outlet air
capacity
[m3/h]
2,95 (*)
700
db (A)
R134a
Coolant
[m / Pa]
Minimum
pipes
diameter
[mm]
8 / 60
180
Max pipes
lenght
(*) according to EN 16147 (T air 20 °C - T water 48,5 °C)
Accessories on request
Thermometer
Art. Nr.
5032240000107
5 units box
Titanium electronic anode
€
80,00
Art. Nr.
€
5200000000008 220,00
100
Model
300
Suitable for
Polywarm®
coated models
Heat transferred
from cold fluid
EVAPORATOR
HEAT PUMP TECHNICAL DATA
CONDENSATOR
Expansion
valve
HEAT PUMP
Heat transferred
to hot fluid
The Bollyterm HP produces DHW thanks to the heat energy naturally present in the
air, allowing considerable energy savings.
The functioning of heat pump is based on the exploitation of a particular ecological
gas (R134) that, through its compression and expansion, ensures high performance
and cost efficiency.
The ener
