Instructions d’ installation
Le mode d’ emploi est inclus avec chaque ensemble du produit. Vous pouvez aussi les consulter ou les télécharger sur www. hilti. ca. En raison de la possibilité de modifications, vérifiez toujours que le mode d’ emploi téléchargé est à jour au moment de son utilisation. Une bonne installation est essentielle pour atteindre une performance optimale. Formation disponible sur demande. Communiquez avec les services techniques de Hilti pour les applications et les conditions non prises en compte dans le mode d’ emploi.
Instructions de commande
Tableau 9. Gamme de produits Hilti KB-TZ2 en acier au carbone
Description
Longueu r( po)
Lettre d’ identifi cation de longueur
Longueu r de filetage( po)
Enrobage nominal 1 po
Épaisseur minimale de fixation 1 po
Épaisseur maximale de fixation 1 po
Enrobag e nominal 2 po
Épaisseur minimale de fixation 2 po
Épaisseur maximale de fixation 2 po
Enrobage nominal 3 po
Épaisseur minimale de fixation 3 po
Épaisseur maximale de fixation 3 po
Enrobage nominal 4 po
Épaisseur minimale de fixation 4 po
Épaisseur maximale de fixation 4 po
KB-TZ2 1 / 4 x 2-1 / 8 2-1 / 8 B 7 / 8 1-3 / 4 0 1 / 8--------- 100 KB-TZ2 1 / 4 x 2-1 / 2 2-1 / 2 C 1-1 / 4 1-3 / 4 0 1 / 2--------- 100 KB-TZ2 1 / 4 x 3-1 / 4 3-1 / 4 D 2 1-3 / 4 0 1-1 / 4--------- 100 KB-TZ2 1 / 4 x 4-1 / 2 4-1 / 2 G 3 1-3 / 4 1 / 8 2-1 / 2--------- 100 KB-TZ2 3 / 8 x 2-1 / 2 2-1 / 2 C 1 1-7 / 8 0 1 / 4--------- 50 KB-TZ2 3 / 8 x 3 3 D 1 1 / 2 1-7 / 8 0 3 / 4 2-1 / 2 0 1 / 4------ 50 KB-TZ2 3 / 8 x 3-1 / 2 3-1 / 2 Ω 2 1-7 / 8 0 1-1 / 4 2-1 / 2 0 3 / 4 3 0 1 / 4--- 50 KB-TZ2 3 / 8 x 3-3 / 4 3-3 / 4 E 2-1 / 4 1-7 / 8 0 1-1 / 2 2-1 / 2 0 1 3 0 1 / 2--- 50 KB-TZ2 3 / 8 x 5 5 H 3-1 / 2 1-7 / 8 0 2-3 / 4 2-1 / 2 0 2-1 / 4 3 0 1-3 / 4--- 50 KB-TZ2 3 / 8 x 7 7 L 4-7 / 8 1-7 / 8 1 / 2 4-3 / 4 2-1 / 2 0 4-1 / 4 3 0 3-3 / 4--- 50 KB-TZ2 1 / 2 x 3 3 D 1-1 / 8 2 1 / 4 1 / 2 2-1 / 2 0 0------ 20 KB-TZ2 1 / 2 x 3-3 / 4 3-3 / 4 E 1-5 / 8 2 1 / 2 1-1 / 4 2-1 / 2 0 3 / 4 3 0 1 / 4--- 20 KB-TZ2 1 / 2 x 4-1 / 2 4-1 / 2 G 2-3 / 8 2 1 / 2 2 2-1 / 2 0 1-1 / 2 3 0 1 3-3 / 4 0 1 / 4 20 KB-TZ2 1 / 2 x 5-1 / 2 5-1 / 2 I 3-3 / 8 2 1 / 2 3 2-1 / 2 0 2-1 / 2 3 0 2 3-3 / 4 0 1-1 / 4 20 KB-TZ2 1 / 2 x 7 7 L 4-3 / 4 2 5 / 8 4-1 / 2 2-1 / 2 1 / 8 4 3 0 3-1 / 2 3-3 / 4 0 2-3 / 4 20 KB-TZ2 1 / 2 x 8-1 / 2 8-1 / 2 O 4-7 / 8 2 2 6 2-1 / 2 1-1 / 2 5-1 / 2 3 1 5 3-3 / 4 1 / 4 4-1 / 4 20 KB-TZ2 1 / 2 x 10 10 R 4-7 / 8 2 3-1 / 2 7-1 / 2 2-1 / 2 3 7 3 2-1 / 2 6-1 / 2 3-3 / 4 1-3 / 4 5-3 / 4 20 KB-TZ2 5 / 8 x 4-1 / 4 4-1 / 4 F 2-1 / 4 3-1 / 4 0 3 / 8--------- 15 KB-TZ2 5 / 8 x 4-3 / 4 4-3 / 4 G 2-3 / 4 3-1 / 4 0 7 / 8 3-3 / 4 0 3 / 8------ 15 KB-TZ2 5 / 8 x 5-1 / 2 5-1 / 2 I 3-1 / 2 3-1 / 4 0 1-5 / 8 3-3 / 4 0 1-1 / 8 4-1 / 2 0 3 / 8--- 15 KB-TZ2 5 / 8 x 6 6 J 4 3-1 / 4 0 2-1 / 8 3-3 / 4 0 1-5 / 8 4-1 / 2 0 7 / 8--- 15 KB-TZ2 5 / 8 x 7 7 L 4-7 / 8 3-1 / 4 0 3-1 / 8 3-3 / 4 0 2-5 / 8 4-1 / 2 0 1-7 / 8--- 15 KB-TZ2 5 / 8 x 8-1 / 2 8-1 / 2 O 6-1 / 2 3-1 / 4 0 4-5 / 8 3-3 / 4 0 4-1 / 8 4-1 / 2 0 3-3 / 8--- 15 KB-TZ2 5 / 8 x 10 10 R 7-1 / 8 3-1 / 4 1 / 8 6-1 / 8 3-3 / 4 0 5-5 / 8 4-1 / 2 0 4-7 / 8--- 15 KB-TZ2 3 / 4 x 4-3 / 4 4-3 / 4 G 2-1 / 2 4 0 1 / 8--------- 10 KB-TZ2 3 / 4 x 5-1 / 2 5-1 / 2 I 3-1 / 4 4 0 7 / 8 4-1 / 2 0 3 / 8------ 10 KB-TZ2 3 / 4 x 6-1 / 4 6-1 / 4 J 3-1 / 4 4 0 1-5 / 8 4-1 / 2 0 1-1 / 8 5-1 / 2 0 1 / 8--- 10 KB-TZ2 3 / 4 x 7 7 L 4 4 0 2-3 / 8 4-1 / 2 0 1-7 / 8 5-1 / 2 0 7 / 8--- 10 KB-TZ2 3 / 4 x 8 8 N 5 4 0 3-3 / 8 4-1 / 2 0 2-7 / 8 5-1 / 2 0 1-7 / 8--- 10 KB-TZ2 3 / 4 x 9 9 P 6 4 0 4-3 / 8 4-1 / 2 0 3-7 / 8 5-1 / 2 0 2-7 / 8--- 10 KB-TZ2 3 / 4 x 10 10 R 7 4 0 5-3 / 8 4-1 / 2 0 4-7 / 8 5-1 / 2 0 3-7 / 8--- 10 KB-TZ2 1x6-1 / 2 6-1 / 2 K 2 1 / 2 4 5 / 8 0 1-1 / 8 6-3 / 8-------- 10 KB-TZ2 1x8 8 N 3 7 / 8 4 5 / 8 0 2-5 / 8 6-3 / 8 0 7 / 8------ 10 KB-TZ2 1x9 9 P 3 7 / 8 4 5 / 8 7 / 8 3-5 / 8 6-3 / 8 0 1-7 / 8------ 10 KB-TZ2 1x10-1 / 2 10-1 / 2 R 6 4 5 / 8 3 / 8 5-1 / 8 6-3 / 8 0 3-3 / 8------ 10 KB-TZ2 1x12 12 T 6 4 5 / 8 1-7 / 8 6-5 / 8 6-3 / 8 1 / 8 4-7 / 8------ 10
Qté dans l’ embal lage
75
