How to Choose the Correct Padlock
Call: 021-508 1250
If you are in the market to purchase a padlock then you most probably want to lock up something valuable or stop someone gaining unauthorised access to an area. Either way, if you make the wrong choice you have wasted your time and your money and made the job of the thief a lot easier.
Your best starting point in deciding on which padlock to purchase is having the correct information to decide on what is the correct choice for your specific needs. Here are a few simple things to consider when making the decision. Applying these principles will guide you through the myriad of different padlocks and marketing jargon which is in the market place, all of them trying to convince you to part with your hard earned money.
Firstly, consider the following points:
How valuable e item you want to protect?
The more valuable the item, the more secure the padlock should be and therefore the higher cost of the padlock.
Consider the complete system you need to use
The padlock is only part of a security system. Thieves target the weakest link in the system, so you will also need to get a high quality hasp or chain. Square link hardened steel chain is the toughest chain you can get.
What is the rating of the padlock?
Padlocks are not created equal, so it is important that for security and insurance purposed the padlock you choose should comply with an independent rating. In South Africa there is a SANS specification for padlocks. When looking for high security padlocks and the padlock complies with the rating then you are assured that it is a quality padlock. When in doubt, choose a quality brand of padlock. It is true, that you get what you pay for. Cheap, high quality padlocks just do not exist.
Do you need a special key system?
Depending on your specific needs, you may need more than one padlock and then you can consider having the padlock as being keyed alike( all padlocks work on one key), or you may need a master keyed system( all padlocks have their own unique key, but there is a single key which can open all the locks in the system).
For very high security systems you should use a restricted keyway, such as the US Patented Edge Key system from Master Lock. This ensures that no unauthorised duplicate keys can be made as there are no key blanks available. Duplicate keys can only be made in the factory for the authorised owner of the system.
The three main components of a padlock include the body, shackle and locking mechanism. Quality of manufacture as well as design and materials used determine the level of security of the padlock. Terms like laminated steel body, dual ball bearing locking mechanism, octagonal shackle and Boron Carbide ensure that you are choosing a padlock which is soundly constructed.
Design and components of a padlock to consider
What size padlock body is correct?
This will be determined by what you are using it for. A huge padlock on a suitcase is inappropriate, as is a small padlock on a garden gate. Your logic will guide you correctly. Also remember that a size alone is a poor indication of the strength of the padlock. Large, cheap padlocks will not offer the correct level of security required.
Which body design is correct?
Padlocks are available in different design configurations, each with their own advantages
Discus type padlocks – have no angular corners and the shackle is well protected. These are often used with cycle chains, security cables and securing door on sheds and garages. These locks offer best value for money.
Shutter style or what is commonly known as“ insurance” padlocks – have a rectangular shape and the securing pin moves between two pillars of the lock. These are popular with roller shutters on shop fronts as well as security chains.
Conventional padlocks – have a body which houses the locking mechanism and the shackle is attached to the body. These are very common padlocks and their application possibilities vary from high security areas to low security situations, depending on their size and type of shackle.
Open type shackles – the shackle is exposed and has no protection.
Closed type shackles – shackle is protected by a shroud on the lock body, this protects the shackle from attack from tools.
Shackles can be normal length or long length. The longer the shackle the easier it is to cut the shackle with bolt cutter or a saw.
Shackle material and shape is also important. The shackle should at least be of hardened steel and plated with chrome or nickel to prevent rust. The ultimate is an octagonal shape shackle made from Boron Carbide, this material is twice as tough as hardened steel and makes the shackle much more cut resistant.
Shackleless padlocks – are unique in that they do have a shackle, but that the shackle is a solid pin that is encased in a solid body and therefore cannot be seen. They need to be used with a specially designed hasp and are used in very high security situations such as warehouse doors.
Which body construction is correct?
The purpose of the lock body is to protect the locking mechanism. It has internal cavities which house the different parts of the locking mechanism. It also has channels to house the shackle of the lock. The main body types are:
Pressed steel – these are two halves of the body which are made from pressed steel and then welded together once the internal parts have been inserted. Discus type locks are usually made in this way.
Solid brass – manufacture of these locks is easy, as brass is soft, however, the soft brass is susceptible to attack by drilling, hammers and crow bars. Brass locks are best used in lower security situations. Sometimes the brass body is armour encased with a hardened steel jacket, this increases the resistance of the soft brass to being attacked.
Laminated steel – the body is constructed of layers of pre-cut steel plates which are then sandwiched and riveted together. This body offers increased security and can be used in high security areas. The Excell and Pro Series padlocks are good examples of this.
Which type of shackle is correct?
Shackles are available in different shapes and materials. Shackle less than 7mm in diameter are considered low security, up to 9mm is medium security and over 9mm as high security.
However, the shape and material used is also important. Material development has shown that an octagonal shackle offers very good resistance to bolt cutters and that Boron Carbide is much tougher than hardened steel. The combination of both makes for a very tough and cut resistant shackle. The only padlocks to use this enhanced and patented design is the Master Lock Excell and Pro Series locks.
Stainless steel shackles are great for outdoors where protection against rust is important, but stainless steel is not the best material to combat being cut by bolt cutters. It is also very expensive.
Which lock mechanism is correct?
Critical elements of the lock mechanism include the locking device, number of pins in the locking cylinder as well as the keyway. The best combination of these features would be having a lock with 6 pins, dual ball bearing locking mechanism and a restricted keyway.
This would mean that the possible key combinations would be more than a million, the shackle would not be able to be pulled out of the lock body and there would not be any key blanks available to make unauthorised duplicate keys.
Many cheap locks with only 4 pins are available with as few as 20 key differs, which make the likelihood of one key being able to open many locks very high. Again, purchase a respected brand of padlock, such as Master Lock to avoid these pitfalls.
Is the lock to be used indoors or outdoors?
If the lock is to be used outdoors, then choose one that is designed to cope with the elements. Some padlocks feature a weatherproofing jacket manufactured from rubber or plastic.
In salty or corrosive environments, a padlock specifically designed for that will need to be used. These locks use materials such as stainless steel and phosphor bronze.
Padlock maintenance
This is an aspect that is overlooked and neglected by most users. A small amount of lubricant applied once or twice a year should be sufficient. Do not use graphite powder or any wet lubricant. These over time damage the internal mechanism of the locks. The best lubricant is a dry type lubricant which contains PTFE, as these lubricants protect the lock and do not attract dust and dirt into the workings of the padlock.
That, in a nutshell is the points you need to consider when choosing the correct padlock for your lockup and security requirements. If you still are unsure, then best go talk to a reputable lock or security specialist who will be able to guide you to make the correct choice.
