Thailand’s Largest Show for Mold & Die Manufacturing
CNC MACHINING CENTER
ITM14020033
1922
BITEC, Bangkok
JIG & CHECKING FIXTURE
Brand : HURCO
Model : VMX24i
•
•
•
•
FEINING TOOLS CO., LTD.
ITM14020034
FILLPART ENGINEERING (1999) CO., LTD.
•
•
•
•
•
Travel: 24 x 20 x 24 in
Table Size: 30 x 20 in
Spindle: 12k, 70 ft-lbs @ 900
Tool Capacity: 24 CAT 40
Machine Weight: 10,225 lbs
CNC HI-SPEED MACHINING
CENTER
ITM14020035
FORCE LINK CO., LTD
ITM14020037
•
•
•
•
FUJILLOY (THAILAND) CO., LTD.
Brand : Ocean
Model : Drilling EDM machine River 300
•
•
•
Table travel (X, Y axes) 300 mm x 200 mm
Work table size 350 mm x 250 mm,
Z axis travel 350 mm, W axis travel 200 mm
The Max. height of workpiece 180 mm
FUKUZAAN CO., LTD.
www.intermoldthailand.com
FORGING DIES
ITM14020038
Brand : Fujilloy
Manufacture of Cemented carbide
Wear-Resistance tools
Made-to-order production of cemented
carbide and steel
Drawing Dies/Plugs (Mandrels),
Roll (Forming Roll, Cold Milling Roll),
Powder Compacting Molds
Carbide Blanks/Preforms, Forging Dies,
Copper Tungsten Electrodes for EDM
DRILLING EDM MACHINE
ITM14020036
FORCE LINK CO., LTD
Brand : Fujilloy
•
•
•
•
FLAT BED CNC LATHE
Spindle bore 120mm is standard. 186mm is option. You can choose Manual
chuck, hydraulic, Pneumatic chuck or double chucks. Turret Vertical 8-sation turret
is standard. You can choose the Horizontal 4-station, 6-station turret, Vertical
12-station driven tool system Double door is standard. According the workpiece to
choose the special guard of HP model.
Tailstock with built-in center is optional.
It use MT#5 Dead center.
Direct-drive spindle provides efficient transmission
and fast CW/CCW revolution. Turret type (armless)
magazine with 14 tools capacity (optional 21 tools)
offers fast tool changing and low broken ratio.
Patented X-axis single piece cover performs only 1.6M
machine front size. Fixed type Y-axis cover assures
low noise and very smooth movement at 48m/min
rapid traverse.
DRAWING DIES/PLUGS
(MANDRELS)
The Receipt of Work : We have the experienced marketing in jig and
fixtures which especially can give advice in concept immediately.
Designing : Our team is experienced in the automotive industry and electronics
as well as 3D design which is easy to monitor the details in virtual reality.
Production : We focus on the modern and precise machinery by using 5 axis
CNC machine in production leading to be precise and time-saving.
Measurement : W e use the standard and highly precise measuring instruments.
Brand : KINWA
Model : CL38
Brand : ARGO
Model : A-60T
56
June 2014
Manufacture of Cemented carbide Wear-Resistance tools
Made-to-order production of cemented carbide and steel
Drawing Dies/Plugs (Mandrels),
Roll (Forming Roll, Cold Milling Roll),
Powder Compacting Molds
Carbide Blanks/Preforms,
Forging Dies, Copper Tungsten
Electrodes for EDM
FUJILLOY (THAILAND) CO., LTD.
ITM14020039
FMV - 45 SERIES 5 - AXIS
MACHINING CENTER
Brand : AWEA
Model : FMV - 45 Series 5 - Axis Machining center
Travel X / Y / Z : 500 x 450 x 450 mm., spindle
speed : 16,000 rpm., Spindle taper : BT 40/HSK
A 63, Cutting feedrate : 24 m/min, X/Y/Z Rapid
feedrate : 48/48/48 m/min., Max table load : 300
kgs., Swiveling range of B axes : -180°/+160°,
Rotary range of C-axis : 360°, Swiveling speed of
B axes : 30 rpm, Rotary speed of C-axis : 100 rpm
FUKUZAAN CO., LTD.
ITM14020040
