T590 W (cód. 0107.392.005)
MAGNUS
Armário expositor de vinhos para 72 garrafas
Wine display unit for 72 bottles
Dimensões (LPA) / Dimensions (WDH)
230V
590x528x1925 mm
Potência / Power
0.275 kW
Temperatura / Temperature
+6 / +12 ºC
Peso / Weight
• Temperatura +6ºC / +12ºC para a exposição de vinho espumante,
vinho branco, vinho tinto novo ou maduro.
• Refrigeração estática, termóstato analógico, iluminação vertical por
LED. Porta em vidro com pega em alumínio e fechadura. Suporte de
garrafas em cromado. Cor wengé.
• Sob pedido: ventilação para temperatura única; disponível na cor
castanho claro ou RAL especial.
98 kg
• Temperature +6 ºC / +12 ºC for the display of sparkling wine, white
wine, red wine.
• Static refrigeration, analogue thermostat, vertical lighting with LED.
• Door with double, shatter-proof glass and handle and lock in
aluminium. Chrome-coated bottle support. “Wengé” colour.
• On request: Ventilation for single temperature, available with the
models in light brown or special RALs.
T830 W (cód. 0107.392.006)
MAGNUS
Armário expositor de vinhos para 108/105 garrafas
Cabinet wine cabinet for 108/105 bottles
Dimensões (LPA) / Dimensions (WDH)
230V
830x528x1925 mm
Potência / Power
0.275 kW
Temperatura/ Temperature
+6 / +12 ºC
Peso/ Weight
• Temperatura +6ºC / +12ºC para a exposição de vinho espumante,
vinho branco, vinho tinto novo ou maduro.
• Refrigeração estática, termóstato analógico, iluminação vertical por
LED. Porta em vidro com pega em alumínio e fechadura. Suporte de
garrafas em cromado. Cor wengé.
• Sob pedido: ventilação para temperatura única; disponível na cor
castanho claro ou RAL especial.
125 kg
• Temperature +6 ºC / +12 ºC for the display of sparkling wine, white
wine, red wine.
• Static refrigeration, analogue thermostat, vertical lighting with LED.
• Door with double, shatter-proof glass and handle and lock in
aluminium. Chrome-coated bottle support. “Wengé” colour.
• On request: Ventilation for single temperature, available with the
models in light brown or special RALs.
T1185 W (cód. 0107.392.007)
MAGNUS
Armário expositor de vinhos para 108/105+36 garrafas
Cabinet wine cabinet for 108/105+36 bottles
Dimensões (LPA) / Dimensions (WDH)
230V
Potência / Power
0.275 kW
Temperatura / Temperature
+6 / +22 ºC
Peso/ Weight
185 kg
• Temperatura +6ºC / +12ºC (lado esquerdo) e +6ºC / +22ºC (lado
direito) para a exposição de vinho espumante, vinho branco, vinho
tinto novo ou maduro.
• Restantes características técnicas iguais ao modelo T830 W.
420
legenda
legend
página opcionais
optionals page
página acessórios
Accessories page
elétrico
eletric
gás
gas
1185x528x1925 mm
• Temperature from +6ºC / +12ºC (left side) and +6ºC to +22ºC (right
side), for the display of sparkling wine, white wine, red wine.
• Other technical characteristics similar to the T830 W model.
voltagem
power supply
classe energética
energy class
