CONTROL SYSTEM The R CT 5023 APPolo Rack Controller is designed for use with the Series | 5000 R FR 5012 and R FR 5014 rack frames. The basic controller module provides network (LAN) access to the rack frame via the APPolo control system hosted in a PC. With the addition of the plug in server option, OH-RCT5023-SVR the APPolo software is hosted on the controller and supports network attached APPolo clients. Multiple server options can be used in a system for redundant backup. Features • Remote control and status monitoring for all installed modules • Network (LAN) access • R FR 5012 and R FR 5014 compatible OH-RCT5023-SVR • USB port on module for local access APPolo Server Option • Upgrade with server option • Includes APPolo software • Hot swappable Ordering Information Description 6150025023 R CT 5023 G - APPolo Network Rack Controller 6155025023 OH-RCT5023-SVR - Plug in APPolo Server Option Network Control Panel The R CP 5044 is a slim 1RU 19” rack mount control panel designed for use with the Series | 5000 product line. The panel can be used with or without the APPolo control system and provides full remote control and monitoring for any Series | 5000 module connected to the system. Features Compact standard 19” Rack mount with 1RU footprint Can be used with or without APPolo control system Display and adj ust all module parameters 4 x user-de?ned alphanumeric RGB backlit push buttons Easy to read monochrome blue backlit display with 2 lines of 40 characters 4 x incremental / push button digital rotary controls with bi-color LED indicators Standard RJ45 LAN connection (100BaseT) Includes 12V modular power supply (external) Features • Single centralized application • User friendly and intuitive GUI • Features ?exGUI Interactive diagram zoom Drag and drop inter-connections Visual path ?nding • HotSync backup utility • Auto discover and con?guration • Error reporting and logging • Software plug-in options APPolo software plug-in options The basic APPolo software has several optional software plug-ins to extend its functionality. There are easily installed by purchasing a license code. Software plug-ins require that the OH-RCT5023-SVR option be installed. OC-RSL-FUNC This package includes the following additional functionality: Backup and Restore - Backup a complete system, or partial system con?guration and the backup ?le on a PC. A backup can be easily restored in the future. This feature is ideal for systems that are used for a multiple of different applications and require different con?gurations. User Access Control - For larger installations with multiple access points, this feature allows the system administrator to control user access rights. In a system with multiple clients, the administrator may want to restrict the ability to change settings and only allow monitoring. This can be set per module function or globally for the entire system. OC-RSL-CTRL This package includes the following additional functionality: SNMP support - This provides full SNMP support for error reporting and control. IP Remote Protocol Licence - This is a user licence for the APPolo control protocol for advanced users and third parties who wish to control LYNX hardware from their own control system. Simple UDP/IP based ASCII text protocol. OC-SERVER-AC-BASE This package includes the following additional functionality: Auto Control - This powerful option provides user programmable automation to the system. APPolo monitors all module settings and I/O (in terms of presence and format) as well as multiple external GPI inputs in real time. Based on these changing conditions, an automatic “action” can be programmed. Ordering Information 44 The APPolo control system is comprised of both software and hardware. Any time a rack controller is installed, APPolo software can be used. The basic APPolo software package is fully featured and free to download from our website. APPolo provides an extremely user friendly and intuitive graphical user interface for the monitoring and control of all connected LYNX hardware. This single, centralized application can be used for a single rack, or literally hundreds of racks located in different locations. Several software plug-in options are available to expand the basic system functionality. R CT 5023 G - APPolo Rack Controller Part # • • • • • • • • APPolo | Control™ with ?exGUI™ ) R CP 5044 R CT 5023 APPolo Network Rack Controller + Server Option CONTROL SYSTEM Ordering Information (Note. All software options require the OH-RCT5023-SVR option installed) Part # Description Part # Description 6155015044 R CP 5044 Network Control Panel and Power Supply 1000000060 OC-RSL-FUNC - Backup and restore and user access control software option (licence code) 6155015016 OPTION: R CP 5016 16-Button Expansion Panel 1000000021 OC-RSL-CTRL - SNMP support and APPolo remote control protocol licence (licence code) 1000000080 OC-SERVER-AC-BASE - Auto control automation software
