CALEO-A2 / DIRECT / OPAL
CALEO-A2 /X2
150˚
180˚
R15-20
150˚
120˚
L
H
LUMEN/WATT
CODE CODE
SILVER WHITE
KG
120˚
LED - MEDIUM POWER
90˚
90˚
L
90
180
60˚
60˚
270
360
30˚
0˚
30˚
5,5
L
H
330 75 1482lm/13W* AA2OSE-###M-Q330 AA2OWE-###M-Q330 4,3
430 75 2673lm/21W* AA2OSE-###M-Q430 AA2OWE-###M-Q430 6,2
530 75 4752lm/36W* AA2OSE-###M-Q530 AA2OWE-###M-Q530 8,8
630 75 5928lm/45W* AA2OSE-###M-Q630 AA2OWE-###M-Q630 12,2
900 75 13337lm/97W* AA2OSE-###M-Q900 AA2OWE-###M-Q900 20,0
LED - HIGH POWER
330 75 2187lm/19W* AA2OSE-###H-Q330 AA2OWE-###H-Q330 4,3
430 75 3525lm/28W* AA2OSE-###H-Q430 AA2OWE-###H-Q430 6,2
530 75 7015lm/54W* AA2OSE-###H-Q530 AA2OWE-###H-Q530 8,8
630 75 8746lm/67W* AA2OSE-###H-Q630 AA2OWE-###H-Q630 12,2
900 75 19680lm/146W* AA2OSE-###H-Q900 AA2OWE-###H-Q900 20,0
LED - TUNABLE WHITE
630 113 4640lm/50W* AA2OSL-8TWM-Q630 AA2OWL-8TWM-Q630 12,2
900 113 10440lm/110W* AA2OSL-8TWM-Q900 AA2OWL-8TWM-Q900 20,0
CALEO-X2 / DIRECT-INDIRECT / OPAL
150˚
180˚
R15-20
150˚
120˚
L
H1
H2
LUMEN/WATT
CODE CODE
SILVER WHITE
KG
120˚
LED - LOW POWER
90˚
90˚
L
90
180
60˚
60˚
270
360
30˚
0˚
30˚
5,5
H1
L
H2
330 55 80 1759lm/15W* AX2OSE-###E-Q330 AX2OWE-###E-Q330 4,0
430 55 80 3072lm/24W* AX2OSE-###E-Q430 AX2OWE-###E-Q430 5,5
530 55 80 5275lm/41W* AX2OSE-###E-Q530 AX2OWE-###E-Q530 7,9
630 55 80 6835lm/52W* AX2OSE-###E-Q630 AX2OWE-###E-Q630 11,1
900 55 80 13472lm/97W* AX2OSE-###E-Q900 AX2OWE-###E-Q900 22,0
LED - MEDIUM POWER
330 55 80 2431lm/20W* AX2OSE-###M-Q330 AX2OWE-###M-Q330 4,0
430 55 80 4526lm/35W* AX2OSE-###M-Q430 AX2OWE-###M-Q430 5,5
530 55 80 7293lm/56W* AX2OSE-###M-Q530 AX2OWE-###M-Q530 7,9
630 55 80 9677lm/73W* AX2OSE-###M-Q630 AX2OWE-###M-Q630 11,1
900 55 80 18970lm/138W* AX2OSE-###M-Q900 AX2OWE-###M-Q900 22,0
E: NON DIMMABLE, D: DIM 1-10V, L: DIM DALI, H: TOUCH-DIM
CONTROL
830 : 3000K, 840 : 4000K
LED COLOUR TEMPERATURE ###
*L e u c h t e n l i c h t s t r o m b e i 4 0 0 0 K
|
Luminaire luminous flux at 40 0 0K
|
Flux de luminaire à 40 0 0K
OPTIONAL
DE EN FR
LED-Anbauleuchte, direktstrahlend für Wand- und
Deckenmontage. Speziell auf LED-Chips abge-
stimmter Opaldiffusor aus satiniertem Acrylglas
für max. Transmissionsgrad und perfekt homogene
Auflösung der Lichtpunkte. LED surface mounted luminaire with direct only
light distribution for walls and ceilings. Specially
adapted to LED-chips, the opal diffuser made
of frosted methacrylate ensures enhanced light
transmission and perfect uniform illumination. Luminaire LED en apparent, éclairage direct. Pour
un montage sur mur et plafond. Spécialement ad-
apté aux puces LED. Diffuseur opale en verre acry-
lique satiné pour un maximum de luminosité et une
diffusion homogène des points lumineux.
Leuchtenkörper fugenlos verschweißt aus Alumini-
um-Strangpress-Profil. Oberfläche in Strukturlack
matt weiß (RAL9003) oder matt silber (RAL9006).
Optional weitere Farben und Oberflächen (s. Ober-
flächenübersicht). Luminaire body made of aluminium-profile without
visible seam. Matt white (RAL9003) or matt silver
(RAL9006) powder-coated. On request extensive
range of alternative colours and surfaces (see over-
view). Corps du luminaire en aluminium extrudé, soudé
sans joint. Surface laquée en blanc mat (RAL9003)
ou gris mat (RAL9006). Couleurs et surfaces supplé-
mentaires en option (voir annexe).
LED-Konverter wahlweise schaltbar oder dimm-
bar (1-10V, DALI , Touch-Dim). Werkseitige Konver-
terprogrammierung ermöglicht unterschiedliche
Lichtstromoptionen. LED drivers which can optionally be switched
or dimmed (1-10V, DALI, Touch-Dim). Factory-set
drivers enable different output levels.
Standard LED-Farbtemperatur 3000K und 4000K.
Auf Wunsch 2200K, 2700K, 3500K, 5000K, 6500K
oder Ausführung TUNABLE WHITE. Enge Farbto-
leranz MacAdam 3. Farbwiedergabe Ra≥84, auf
Anfrage Ra>90 möglich.
Hohe Wartungs- und Installationsfreundlichkeit
durch werkzeuglosen Zugang zu LED-Platinen und
-Konverter.
Lichtstromrückgang auf 90% des Ursprungswertes
bei 50000h (L90B10 bei 25°C und max. Medium-
Power). 5 Jahre Garantie auf LED-Module und LED-
Betriebsgeräte.
Beachten Sie die Übersicht `optionale Ausführungen`
Standard LED colour temperature 3000K and
4000K. On request 2200K, 2700K, 3500K, 5000K,
6500K. TUNABLE WHITE version possible.
MacAdam 3 step binning. Colour rendering CRI≥84,
CRI>90 on request.
Direct access to integral drivers and LED circuit
boards ensures hassle-free installation and main-
tenance.
90% of initial output for 50000 operating hours
(L90B10 at 25°C and max. Medium-Power). 5 year
warranty on all LED boards and LED drivers.
Refer to "options" overview
WHITE KROKO
SURFACE CODE: K: SPARKLING ANTHRACITE
SURFACE CODE: D BLACK RAVEN
SURFACE CODE: B
MAJESTIC GOLD
SURFACE CODE: G COZY COPPER
SURFACE CODE: M STALWART RUST
SURFACE CODE: U
Convertisseur LED au choix: commutable ou gra-
duable (1-10V, DALI, Touch-Dim). Programmation en
usine offrant différentes options de flux lumineux.
Température de couleur LED standard 3000K ou
4000K. Sur demande: 2200K, 2700K, 3500K, 5000K,
6500K (MacAdam 3) ou version tunable white. Ren-
du de couleur IRC≥84, sur demande IRC>90.
Accès direct aux convertisseurs et platines LED
assurant l'installation et l'entretien sans outil.
50 000 heures de fonctionnement avec une uti-
lisation à 90% de la puissance (L90B10 à 25°C
et max. Medium-Power). 5 ans de garantie sur tous
les modules LED et convertisseurs LED.
Voir les différentes options
ALTERNATIVE COLOUR
TEMPERATURES:
2200K/ 3500K/ 6500K
LEDS WITH
HIGHER CRI
Ra>90
FURTHER SELECTED
SURFACE DESIGNS:
SEE PAGE 15
BLUETOOTH
MODULE FOR
WIRELESS CONTROL
EMERGENCY
MODULE WITH
3 HOUR BATTERY
RADAR SENSOR
FOR HIGH FREQUENCY
MOTION CONTROL
