MATRIC-M3 / FRAMELESS 55MM / MICROPRISMATIC
MATRIC-M3 / FRAMELESS 55MM / SATIN LOUVER
PLEASE ORDER SEPARATELY:
FRAME FOR INSTALLATION WITH SHADOW GAP
OR
120˚
90˚
60˚
150˚
30˚
BRACKET FOR INSTALLATION WITHOUT SHADOW GAP
180˚
150 300
450 600
0˚
150˚
30˚
120˚
90˚
60˚
55
75
L1
L1
LUMEN / WATT
CODE
KG
LED- LOW POWER
890
1767lm / 17W *
LM3AEE- ### E-L890
2,4
1182
2356lm / 21W *
LM3AEE- ### E-L1182
2,9
1475
2945lm / 26W *
LM3AEE- ### E-L1475
3,5
1765
3534lm / 31W *
LM3AEE- ### E-L1765
4,1
2350
4712lm / 40W *
LM3AEE- ### E-L2350
5,5
2930
5889lm / 49W *
LM3AEE- ### E-L2930
7,1
LED- MEDIUM POWER
890
2420lm / 23W *
LM3AEE- ### M-L890
2,4
1182
3226lm / 30W *
LM3AEE- ### M-L1182
2,9
1475
4033lm / 36W *
LM3AEE- ### M-L1475
3,5
1765
4840lm / 43W *
LM3AEE- ### M-L1765
4,1
2350
6453lm / 57W *
LM3AEE- ### M-L2350
5,5
2930
8067lm / 70W *
LM3AEE- ### M-L2930
7,1
LED- HIGH POWER
890
3496lm / 34W *
LM3AEE- ### H-L890
2,4
1182
4662lm / 45W *
LM3AEE- ### H-L1182
2,9
1475
5827lm / 56W *
LM3AEE- ### H-L1475
3,5
1765
6993lm / 66W *
LM3AEE- ### H-L1765
4,1
2350
9324lm / 87W *
LM3AEE- ### H-L2350
5,5
2930
11655lm / 109W *
LM3AEE- ### H-L2930
7,1
FLUORESCENT
PLEASE ORDER SEPARATELY:
FRAME FOR INSTALLATION WITH SHADOW GAP
OR
120˚
90˚
60˚
150˚
30˚
BRACKET FOR INSTALLATION WITHOUT SHADOW GAP
180˚
100 200 300 0˚
150˚
30˚
120˚
90˚
60˚
55
75
L1
L1
LAMPS
CODE
KG
LED MEDIUM POWER
890
1654lm / 23W *
LM3MEE- ### M-L890
2,4
1182
2206lm / 30W *
LM3MEE- ### M-L1182
2,9
1475
2758lm / 36W *
LM3MEE- ### M-L1475
3,5
1765
3310lm / 43W *
LM3MEE- ### M-L1765
4,1
2350
4412lm / 57W *
LM3MEE- ### M-L2350
5,5
2930
5515lm / 70W *
LM3MEE- ### M-L2930
7,1
FLUORESCENT
878
T5 1x21 / 39W
LM3MEET-121 / 39
3,9
1182
T5 1x28 / 54W
LM3MEET-128 / 54
5,0
1486
T5 1x35 / 49 / 80W
LM3MEET-135 / 49 / 80
6,4
1754
T5 2x1x21 / 39W
LM3MEET-2-121 / 39
7,3
2362
T5 2x1x28 / 54W
LM3MEET-2-128 / 54
9,6
2970
T5 2x1x35 / 49W
LM3MEET-2-135 / 49
12,6
2970
T5 2x1x80W
LM3MEET-2-180
14,5
3542
T5 3x1x28 / 54W
LM3MEET-3-128 / 54
19,2
4454
T5 3x1x35 / 49W
LM3MEET-3-135 / 49
10,5
4454
T5 3x1x80W
LM3MEET-3-180
10,5
CONTROL
E: NON DIMMABLE, D: DIM 1-10V, L: DIM DALI, H: TOUCH-DIM
LED COLOUR TEMPERATURE ###
830: 3000K, 840: 4000K
* Leuchtenlichtstrom bei 4000K | Luminaire luminous flux at 4000K | Flux de luminaire à 4000K
878
T5 1x21 / 39W
LM3AEET-121 / 39
2,3
1182
T5 1x28 / 54W
LM3AEET-128 / 54
2,8
MATRIC-M3 / FRAMELESS 55MM / WALLWASHER
1486
T5 1x35 / 49 / 80W
LM3AEET-135 / 49 / 80
3,4
1682
T5 2x1x21 / 39W
LM3AEET-2-121 / 39
3,9
2290
T5 2x1x28 / 54W
LM3AEET-2-128 / 54
5,3
2898
T5 2x1x35 / 49W
LM3AEET-2-135 / 49
6,9
3400
T5 3x1x28 / 54W
LM3AEET-3-128 / 54
8,4
4310
T5 3x1x35 / 49W
LM3AEET-3-135 / 49
10,5
120˚
90˚
60˚
150˚
30˚
180˚
140
280
420
560 0˚
150˚
30˚
120˚
90˚
60˚
55
75
L1
L1
LUMEN / WATT
CODE
KG
LED- MEDIUM POWER
890
1160lm / 17W *
LM3GEE- ### M-L890
2,4
1182
1550lm / 22W *
LM3GEE- ### M-L1182
2,9
1475
1932lm / 26W *
LM3GEE- ### M-L1475
3,5
1765
2320lm / 31W *
LM3GEE- ### M-L1765
4,1
CONTROL LED COLOUR TEMPERATURE ###
E: NON DIMMABLE, D: DIM 1-10V, L: DIM DALI, H: TOUCH-DIM 830: 3000K, 840: 4000K
2350
3100lm / 40W *
LM3GEE- ### M-L2350
5,5
2930
3865lm / 49W *
LM3GEE- ### M-L2930
7,1
* Leuchtenlichtstrom bei 4000K | Luminaire luminous flux at 4000K | Flux de luminaire à 4000K
CONTROL LED COLOUR TEMPERATURE ###
E: NON DIMMABLE, D: DIM 1-10V, L: DIM DALI, H: TOUCH-DIM 830: 3000K, 840: 4000K
PLEASE ORDER SEPARATELY: * Leuchtenlichtstrom bei 4000K | Luminaire luminous flux at 4000K | Flux de luminaire à 4000K
MATRIC-M3 / FRAMELESS 55MM / OPAL
120˚
90˚
60˚
150˚
30˚
180˚
120 240
360 480 0˚
150˚
30˚
120˚
90˚
60˚
55
75
L1
L1
LUMEN / WATT
CODE
KG
LED- LOW POWER
890
1866lm / 17W *
LM3OEE- ### E-L890
2,4
1182
2490lm / 21W *
LM3OEE- ### E-L1182
2,9
1475
3110lm / 26W *
LM3OEE- ### E-L1475
3,5
FRAME FOR INSTALLATION WITH SHADOW GAP
1765 3732lm / 31W * LM3OEE- ### E-L1765 4,1
2350 4976lm / 40W * LM3OEE- ### E-L2350 5,5
2930 6220lm / 49W * LM3OEE- ### E-L2930 7,1
PLEASE ORDER SEPARATELY:
LED- MEDIUM POWER
890
2556lm / 23W *
LM3OEE- ### M-L890
2,4
1182
3408lm / 30W *
LM3OEE- ### M-L1182
2,9
1475
4260lm / 36W *
LM3OEE- ### M-L1475
3,5
MATRIC-M3 / FRAME FOR INSTALLATION WITH SHADOW GAP
95 × L2
L1 L2 CODE KG
FRAME FOR INSTALLATION WITH SHADOW GAP
OR
BRACKET FOR INSTALLATION WITHOUT SHADOW GAP
1765
5113lm / 43W *
LM3OEE- ### M-L1765
4,1
2350
6817lm / 57W *
LM3OEE- ### M-L2350
5,5
2930
8521lm / 70W *
LM3OEE- ### M-L2930
7,1
LED- HIGH POWER
890
3693lm / 34W *
LM3OEE- ### H-L890
2,4
1182
4924lm / 45W *
LM3OEE- ### H-L1182
2,9
1475
6156lm / 56W *
LM3OEE- ### H-L1475
3,5
100
LED DRIVER
2,5 55
62 95
90
12-28 min. 130
CODES FOR LED VERSION LUMINAIRES( T5 ON THE REQUEST) 890 905 LM3-FRAME-L890 1,4 1182 1197 LM3-FRAME-L1182 1,9 1475 1490 LM3-FRAME-L1475 2,2 1765 1780 LM3-FRAME-L1765 3,1 2350 2365 LM3-FRAME-L2350 3,6 2930 2945 LM3-FRAME-L2930 4,2
467
1765 7387lm / 66W * LM3OEE- ### H-L1765 4,1 2350 9849lm / 87W * LM3OEE- ### H-L2350 5,5
2930 12311lm / 109W * LM3OEE- ### H-L2930 7,1
L1
FLUORESCENT
L2
878 T5 1x21 / 39W LM3OEET-121 / 39 2,3
1182
T5 1x28 / 54W
LM3OEET-128 / 54
2,8
1486
T5 1x35 / 49 / 80W
LM3OEET-135 / 49 / 80
3,4
MATRIC-M3 / BRACKET FOR INSTALLATION WITHOUT SHADOW GAP
1682
T5 2x1x21 / 39W
LM3OEET-2-121 / 39
3,9
2290
T5 2x1x28 / 54W
LM3OEET-2-128 / 54
5,3
2898
T5 2x1x35 / 49W
LM3OEET-2-135 / 49
6,9
3400
T5 3x1x28 / 54W
LM3OEET-3-128 / 54
8,4
4310
T5 3x1x35 / 49W
LM3OEET-3-135 / 49
10,5
56 × L2
12-28
LED DRIVER
55
56
75
min. 135
L1 L2 CODE AMOUNT PER LUMINAIRE
AMOUNT FOR LED VERSION LUMINAIRES( T5 ON THE REQUEST)
890 891 LM3-BRACKET 2
1182 1183 LM3-BRACKET 2
1475 1476 LM3-BRACKET 2
CONTROL
E: NON DIMMABLE, D: DIM 1-10V, L: DIM DALI, H: TOUCH-DIM
LED COLOUR TEMPERATURE ###
830: 3000K, 840: 4000K
* Leuchtenlichtstrom bei 4000K | Luminaire luminous flux at 4000K | Flux de luminaire à 4000K
1765 1766 LM3-BRACKET 2 2350 2351 LM3-BRACKET 3 2930 2931 LM3-BRACKET 3
