CALEO-L1 |
CALEO-L1 / FRAMELESS / MICROPRISMATIC
150˚ 180˚ 150˚ 56 × L2
120˚ 120˚
90˚
90˚
150 300
60˚
60˚ 450 600 max 16 30˚ 0˚ 30˚ min 8
|
55 |
75 |
max 140 |
|
||||||||||||||||||||||||||||||||||
1765 1766 4840lm / 43W * AL1AEE- ### M-L1765 3,8 |
|||||||||||||||||||||||||||||||||||||||
100 |
2350 2351 6453lm / 57W * AL1AEE- ### M-L2350 4,2 |
||||
2930 2931 8067lm / 70W * AL1AEE- ### M-L2930 5,0 |
|
120˚
90˚
60˚
|
150˚
30˚
|
180˚
120 240
360 480 0˚
|
150˚
30˚
|
120˚
90˚
60˚
|
56 × L2
max 16 min 8
|
75 |
max 140 |
|
|||||||||||||||||||||||||
55 |
1475 1476 4260lm / 36W * AL1OEE- ### M-L1475 2,5 |
|||||||
100 |
|
|||||||||||||||||
2930 2931 8521lm / 70W * AL1OEE- ### M-L2930 5,0 |
|
Rahmenlose LED-Einbau-Lichtlinie, direktstrahlend. Microprismenoptik aus Spezialacrylglas bildschirmarbeitsplatztauglich nach EN 12464-1( UGR < 19) alternativ Opaldiffusor mit perfekt homogener Auflösung der Lichtpunkte.
Leuchtenkörper aus Aluminium-Strangpressprofil, weiß pulverlackiert. Beliebige Längen als durchgängiges Lichtband sowie Vielzahl möglicher Konfigurationen erhältlich.
LED-Konverter wahlweise schaltbar oder dimmbar( 1-10V, DALI, Touch-Dim). Werkseitige Konverterprogrammierung ermöglicht unterschiedliche Lichtstromoptionen.
Standard LED-Farbtemperatur 3000K und 4000K. Auf Wunsch 2200K, 2700K, 3500K, 5000K, 6500K. Enge Farbtoleranz MacAdam 3. Farbwiedergabe Ra≥84, auf Anfrage Ra > 90 möglich.
Geeignet für rahmenlose Montage in Gipskartondecken- und wänden, Befestigungsset inkl.
Lichtstromrückgang auf 80 % des Ursprungswertes bei 50000h( L80B10 bei 25 ° C und max. Medium- Power). 5 Jahre Garantie auf LED-Module und LED- Betriebsgeräte.
Beachten Sie die Übersicht `optionale Ausführungen`
|
Recessed mounted LED light line( frameless) with direct only light distribution. Microprismatic screen for glare-free illumination according to EN 12464-1( UGR < 19) optionally opal diffuser for perfect uniform and enhanced light transmission.
Luminaire body made of white powder coated aluminium-profile. Custom lenghts as continuous light line with multiple configurations available.
LED drivers optionally switched or dimmed( 1-10V, DALI, Touch-Dim). Factory-set drivers enable different output levels.
Standard LED colour temperature 3000K and 4000K. On request 2200K, 2700K, 3500K, 5000K, 6500K. MacAdam 3 step binning. Colour rendering CRI≥84, CRI > 90 on request.
Suitable for frameless installation in plasterboard ceilings and plasterboard walls, mounting brackets incl.
90 % of initial output after 50000 operating hours( L90B10 at 25 ° C and max. Medium-Power). 5 year warranty on all LED boards and LED drivers.
Refer to " options " overview
|
Ligne de lumière LED encastrée, éclairage direct. Diffuseur micro-prismatique en verre acrylique adapté pour les postes de travail et conforme selon la norme EN 12464-1( UGR < 19), en option: diffuseur opale avec une diffusion homogène des points lumineux.
Corps en aluminium extrudé laqué en blanc. Toutes les longueurs de bande lumineuse continue sont possibles ainsi qu ' un grand nombre d ' autres configurations.
Convertisseurs LED au choix: commutable ou graduable( 1-10V, DALI, Touch-Dim). Programmation en usine offrant différentes options de flux lumineux.
Température de couleur LED standard 3000K ou 4000K. Sur demande: 2200K, 2700K, 3500K, 5000K, 6500K( MacAdam 3). Rendu de couleur IRC≥84, sur demande IRC > 90.
Approprié pour une installation sans cadre sur les plafonds et murs en plâtre, support de fixation inclus.
50 000 heures de fonctionnement avec une utilisation à 80 % de la puissance( L80B10 à 25 ° C et max. Medium-Power). 5 ans de garantie sur tous les modules LED et convertisseurs LED.
Voir les différentes options
|
OPTIONAL
ALTERNATIVE COLOUR TEMPERATURES: 2200K / 3500K / 6500K
|
LEDS WITH HIGHER CRI Ra > 90 |
BLUETOOTH MODULE FOR WIRELESS CONTROL |
EMERGENCY MODULE WITH 3 HOUR BATTERY |
RADAR SENSOR FOR HIGH FREQUENCY MOTION CONTROL |
433 |
