MATRIC-A5 / DIRECT / WALLWASHER
MATRIC-A5 / DIRECT / MICROPRISMATIC
150˚
180˚
150˚
120˚
L2
100
120˚
90˚
L1
82
90˚
300
60˚
450
600
30˚
0˚
LUMEN/WATT
CODE
150˚
KG
82
30˚
L1
180˚
L2
150˚
120˚
LED - LOW POWER
150
60˚
L2
100
120˚
600 200 1535lm/17W* LA5AEE-###E-L600 2,6
890 490 2303lm/23W* LA5AEE-###E-L890 3,0
1182 782 3071lm/30W* LA5AEE-###E-L1182 3,6
1475 1075 3893lm/36W* LA5AEE-###E-L1475 4,2
1765 1365 4607lm/42W* LA5AEE-###E-L1765 2350 1950 6143lm/56W* 2930 2530
90˚
90˚
140
82
280
60˚
420
560
0˚
60˚
200
L2
LUMEN/WATT
CODE
KG
600 200 773lm/12W* LA5GEE-###M-L600 3,1
890 490 1160lm/17W* LA5GEE-###M-L890 3,9
1182 782 1550lm/22W* LA5GEE-###M-L1182 4,8
1475 1075 1932lm/26W* LA5GEE-###M-L1475 5,7
5,6 1765 1365 2320lm/31W* LA5GEE-###M-L1765 7,3
LA5AEE-###E-L2350 6,8 2350 1950 3100lm/40W* LA5GEE-###M-L2350 9,1
7678m/69W* LA5AEE-###E-L2930 8,3 2930 2530 3865lm/49W* LA5GEE-###M-L2930 11,3
2235lm/23W* LA5AEE-###M-L600 2,6
30˚
30˚
L1
LED - MEDIUM POWER
600
L1
LED - MEDIUM POWER
82
890 490 3353lm/34W* LA5AEE-###M-L890 3,0
1182 782 4470lm/44W* LA5AEE-###M-L1182 3,6
1475 1075 5587lm/54W* LA5AEE-###M-L1475 4,2
1765 1365 6705lm/64W* LA5AEE-###M-L1765 5,6
2350 1950 8940lm/85W* LA5AEE-###M-L2350 6,8
2930 2530 11176lm/106W* LA5AEE-###M-L2930 8,3
E: NON DIMMABLE, D: DIM 1-10V, L: DIM DALI, H: TOUCH-DIM
CONTROL
830 : 3000K, 840 : 4000K
LED COLOUR TEMPERATURE ###
*L e u c h t e n l i c h t s t r o m b e i 4 0 0 0 K
|
Luminaire luminous flux at 40 0 0K
|
Flux de luminaire à 40 0 0K
FLUORESCENT
1182 782 T5 1x28/54W LA5AEET-128/54 3,5
1182 782 T5 2x28/54W LA5AEET-228/54 3,6
1486 1086 T5 1x35/49/80W LA5AEET-135/49/80 4,0
1486 1086 T5 2x35/49W LA5AEET-235/49 4,1
2290 1890 T5 2x1x28/54W LA5AEET-2-128/54 6,3
2450 2050 T5 2x2x28/54W LA5AEET-2-228/54 6,3
2898 2498 T5 2x1x35/49/80W LA5AEET-2-135/49/80 7,6
3050 2650 T5 2x2x35/49W LA5AEET-2-235/49 7,6
3400 3000 T5 3x1x28/54W LA5AEET-3-128/54 9,8
3635 3235 T5 3x2x28/54W LA5AEET-3-228/54 9,8
MATRIC-A5 / DIRECT / OPAL
150˚
180˚
150˚
120˚
L2
100
120˚
90˚
82
90˚
60˚
30˚
360
480
0˚
60˚
L2
LUMEN/WATT
CODE
KG
LED - LOW POWER
120
240
L1
82
30˚
L1
600 200 1769lm/17W* LA5OEE-###E-L600 890 490 2654lm/23W* LA5OEE-###E-L890
2,6
3,0
1182 782 3538lm/30W* LA5OEE-###E-L1182 3,6
4,2
1475 1075 4423lm/36W* LA5OEE-###E-L1475 1765 1365 5307lm/42W* LA5OEE-###E-L1765 5,6
2350 1950 7077lm/56W* LA5OEE-###E-L2350 6,8
2930 2530 8846m/69W* LA5OEE-###E-L2930 8,3
2,6
LED - MEDIUM POWER
600 200 2575lm/23W* LA5OEE-###M-L600 890 490 3862lm/34W* LA5OEE-###M-L890 3,0
1182 782 5150lm/44W* LA5OEE-###M-L1182 3,6
1475 1075 6437lm/54W* LA5OEE-###M-L1475 4,2
1765 1365 7724lm/64W* LA5OEE-###M-L1765 5,6
2350 1950 10299lm/85W* LA5OEE-###M-L2350 6,8
2930 2530 12874lm/106W* LA5OEE-###M-L2930 8,3
2,6
OPTIONAL
393
LED - HIGH POWER
600 200 3331lm/31W* LA5OEE-###H-L600 890 490 4997lm/45W* LA5OEE-###H-L890 3,0
1182 782 6663lm/60W* LA5OEE-###H-L1182 3,6
4,2
1475 1075 8329lm/74W* LA5OEE-###H-L1475 1765 1365 9994lm/88W* LA5OEE-###H-L1765 5,6
2350 1950 13326lm/117W* LA5OEE-###H-L2350 6,8
2930 2530 16657lm/145W* LA5OEE-###H-L2930 8,3
SPOTLIGHT TYPE: MR
MAX. 800LM SPOTLIGHT TYPE: AC
MAX. 500LM SPOTLIGHT TYPE: RX3
MAX. 1300LM SPOTLIGHT TYPE: RX5
MAX. 4000LM 3-PHASE TRACK WHITE KROKO
SURFACE CODE: K: SPARKLING ANTHRACITE
SURFACE CODE: D BLACK RAVEN
SURFACE CODE: B MAJESTIC GOLD
SURFACE CODE: G COZY COPPER
SURFACE CODE: M STALWART RUST
SURFACE CODE: U
ALTERNATIVE COLOUR
TEMPERATURES:
2200K/ 3500K/ 6500K LEDS WITH
HIGHER CRI
Ra>90 FURTHER SELECTED
SURFACE DESIGNS:
SEE PAGE 15 BLUETOOTH
MODULE FOR
WIRELESS CONTROL EMERGENCY
MODULE WITH
3 HOUR BATTERY MULTISENSOR
FOR DAYLIGHT AND
PRESENCE CONTROL
FLUORESCENT
1182 782 T5 1x28/54W LA5OEET-128/54 3,5
1182 782 T5 2x28/54W LA5OEET-228/54 3,6
1486 1086 T5 1x35/49/80W LA5OEET-135/49/80 4,0
1486 1086 T5 2x35/49W LA5OEET-235/49 4,1
2290 1890 T5 2x1x28/54W LA5OEET-2-128/54 6,3
2450 2050 T5 2x2x28/54W LA5OEET-2-228/54 6,3
2898 2498 T5 2x1x35/49W LA5OEET-2-135/49 7,6
3050 2650 T5 2x2x35/49W LA5OEET-2-235/49 7,6
3400 3000 T5 3x1x28/54W LA5OEET-3-128/54 9,8
3635 3235 T5 3x2x28/54W LA5OEET-3-228/54 9,8
E: NON DIMMABLE, D: DIM 1-10V, L: DIM DALI, H: TOUCH-DIM
CONTROL
830 : 3000K, 840 : 4000K
LED COLOUR TEMPERATURE ###
*L e u c h t e n l i c h t s t r o m b e i 4 0 0 0 K
|
Luminaire luminous flux at 40 0 0K
|
Flux de luminaire à 40 0 0K
