BASIC-A1 |
BASIC-A1 / DIRECT / MICROPRISMATIC
120˚
90˚
60˚
150˚
30˚
180˚
135
270
405
540 0˚
150˚
30˚
120˚
90˚
60˚
|
H |
D H LUMEN / WATT CODE CODE KG
LED- LOW POWER SILVER WHITE
200 75 797lm / 9W * BA1ASE- ### E-D200 BA1AWE- ### E-D200 2,5
300 75 1217lm / 12W * BA1ASE- ### E-D300 BA1AWE- ### E-D300 3,3
400 75 2272lm / 19W * BA1ASE- ### E-D400 BA1AWE- ### E-D400 5,1
|
||||||
500 75 3258lm / 27W * BA1ASE- ### E-D500 BA1AWE- ### E-D500 7,1 |
|||||||||
600 75 4566lm / 37W * BA1ASE- ### E-D600 BA1AWE- ### E-D600 9,7 |
|||||||||
970 75 9000lm / 74W * BA1ASE- ### E-D970 BA1AWE- ### E-D970 29,0 |
|||||||||
D |
1200 75 13500lm / 111W * BA1ASE- ### E-D1200 BA1AWE- ### E-D1200 39,0 |
||||||||
LED- MEDIUM POWER SILVER WHITE | |||||||||
200 75 1095lm / 12W * BA1ASE- ### M-D200 BA1AWE- ### M-D200 2,5 | |||||||||
300 75 1681m / 16W * BA1ASE- ### M-D300 BA1AWE- ### M-D300 3,3 | |||||||||
400 75 3347lm / 29W * BA1ASE- ### M-D400 BA1AWE- ### M-D400 5,1 | |||||||||
500 75 4500lm / 37W * BA1ASE- ### M-D500 BA1AWE- ### M-D500 7,1 | |||||||||
600 75 6736lm / 54W * BA1ASE- ### M-D600 BA1AWE- ### M-D600 9,7 | |||||||||
970 75 13220lm / 110W * BA1ASE- ### M-D970 BA1AWE- ### M-D970 29,0 | |||||||||
1200 75 19831lm / 167W * BA1ASE- ### M-D1200 BA1AWE- ### M-D1200 39,0 | |||||||||
LED- TUNABLE WHITE SILVER WHITE | |||||||||
700 113 6600lm / 60W * BA1ASL-8TWM-D700 BA1AWL-8TWM-D700 14,8 | |||||||||
970 113 13220lm / 170W * BA1ASL-8TWM-D970 BA1AWL-8TWM-D970 29,0 | |||||||||
FLUORESCENT SILVER WHITE | |||||||||
300 75 TR-5 1x22W BA1ASER-122 BA1AWER-122 2,3 | |||||||||
400 75 TR-5 1x22 + 40W BA1ASER-122-40 BA1AWER-122-40 3,6 | |||||||||
400 75 TR-5 1x40W BA1ASER-140 BA1AWER-140 3,6 | |||||||||
400 75 TR-5 1x55W BA1ASER-155 BA1AWER-155 3,6 | |||||||||
500 75 TR-5 1x60W BA1ASER-160 BA1AWER-160 4,8 | |||||||||
500 75 TR-5 1x40 + 60W BA1ASER-140-60 BA1AWER-140-60 4,8 | |||||||||
650 113 T5 4x24 + TC-L 2x24 BA1ASEL-424-224 BA1AWEL-424-224 8,8 |
BASIC-A1 / DIRECT / OPAL |
970 113 T5 4x21 + 6x14W BA1ASET-421-614 BA1AWET-421-614 17,2 |
||||||||
120˚ |
150˚ |
180˚ |
150˚ |
120˚ |
H |
D H LUMEN / WATT CODE CODE KG
LED- LOW POWER SILVER WHITE
|
|||
|
90˚
60˚
|
30˚ |
90
180
270 360
0˚
|
30˚ |
90˚
60˚
|
200 75 836lm / 9W * BA1OSE- ### E-D200 BA1OWE- ### E-D200 2,5
300 75 1277lm / 12W * BA1OSE- ### E-D300 BA1OWE- ### E-D300 3,3
400 75 2382lm / 19W * BA1OSE- ### E-D400 BA1OWE- ### E-D400 5,1
|
||||
500 75 3416lm / 27W * BA1OSE- ### E-D500 BA1OWE- ### E-D500 7,1 |
|||||||||
600 75 4787lm / 37W * BA1OSE- ### E-D600 BA1OWE- ### E-D600 9,7 |
|||||||||
970 75 9436lm / 74W * BA1OSE- ### E-D970 BA1OWE- ### E-D970 29,0 |
|||||||||
D |
1200 75 14154lm / 111W * BA1OSE- ### E-D1200 BA1OWE- ### E-D1200 39,0 |
||||||||
LED- MEDIUM POWER SILVER WHITE |
||||||||||||||||||
200 75 1149lm / 12W * BA1OSE- ### M-D200 BA1OWE- ### M-D200 2,5 |
||||||||||||||||||
300 75 1761lm / 16W * BA1OSE- ### M-D300 BA1OWE- ### M-D300 3,3 |
||||||||||||||||||
400 75 3509lm / 29W * BA1OSE- ### M-D400 BA1OWE- ### M-D400 5,1 |
||||||||||||||||||
500 75 4718lm / 37W * BA1OSE- ### M-D500 BA1OWE- ### M-D500 7,1 |
||||||||||||||||||
600 75 7062lm / 54W * BA1OSE- ### M-D600 BA1OWE- ### M-D600 9,7 |
||||||||||||||||||
970 75 13865lm / 110W * BA1OSE- ### M-D970 BA1OWE- ### M-D970 29,0 |
||||||||||||||||||
|
DE EN FR
LED-Anbauleuchte, direktstrahlend für Wand- und Deckenmontage. Microprismenoptik aus Spezialacrylglas bildschirmarbeitsplatztauglich nach EN 12464-1( UGR < 19) alternativ Opaldiffusor aus satiniertem Acrylglas mit perfekt homogener Auflösung der Lichtpunkte.
Leuchtenkörper fugenlos verschweißt aus Aluminium-Strangpress-Profil. Oberfläche in Strukturlack matt weiß( RAL9003) oder matt silber( RAL9006). Optional weitere Farben und Oberflächen( s. Oberflächenübersicht).
LED-Konverter wahlweise schaltbar oder dimmbar( 1-10V, DALI, Touch-Dim). Werkseitige Konverterprogrammierung ermöglicht unterschiedliche Lichtstromoptionen.
Standard LED-Farbtemperatur 3000K und 4000K. Auf Wunsch 2200K, 2700K, 3500K, 5000K, 6500K oder Ausführung TUNABLE WHITE. Enge Farbtoleranz MacAdam 3. Farbwiedergabe Ra≥84, auf Anfrage Ra > 90 möglich.
Hohe Wartungs- und Installationsfreundlichkeit durch werkzeuglosen Zugang zu LED-Platinen und-Konverter.
Lichtstromrückgang auf 90 % des Ursprungswertes bei 50000h( L90B10 bei 25 ° C und max. Medium- Power). 5 Jahre Garantie auf LED-Module und LED- Betriebsgeräte.
LED surface mounted luminaire with direct only light distribution for walls and ceilings. Microprismatic screen for glare-free illumination according to EN 12464-1( UGR < 19) optional opal diffuser for enhanced light transmission and perfect uniform illumination.
Luminaire body made of aluminium-profile without visible seam. Matt white( RAL9003) or matt silver( RAL9006) powder-coated. On request extensive range of alternative colours and surfaces( see overview).
LED drivers which can optionally be switched or dimmed( 1-10V, DALI, Touch-Dim). Factory-set drivers enable different output levels.
Standard LED colour temperature 3000K and 4000K. On request 2200K, 2700K, 3500K, 5000K, 6500K. TUNABLE WHITE version possible. MacAdam 3 step binning. Colour rendering CRI≥84, CRI > 90 on request.
Direct access to integral drivers and LED circuit boards ensures hassle-free installation and maintenance.
90 % of initial output for 50000 operating hours( L90B10 at 25 ° C and max. Medium-Power). 5 year warranty on all LED boards and LED drivers.
Refer to " options " overview
Luminaire LED en apparent, éclairage direct pour un montage sur plafond ou mur. Diffuseur micro-prismatique en verre acrylique adapté pour les postes de travail et conforme selon la norme EN 12464-1( UGR < 19), en option: diffuseur opale en verre acrylique satiné avec une diffusion homogène des points lumineux.
Corps du luminaire en aluminium extrudé, soudé sans joint. Surface laquée en blanc mat( RAL9003) ou gris mat( RAL9006). Couleurs et surfaces supplémentaires en option( voir annexe).
Convertisseur LED au choix: commutable ou graduable( 1-10V, DALI, Touch-Dim). Programmation en usine offrant différentes options de flux lumineux.
Température de couleur LED standard 3000K ou 4000K. Sur demande: 2200K, 2700K, 3500K, 5000K, 6500K( MacAdam 3) ou version TUNABLE WHITE. Rendu de couleur IRC≥84, sur demande IRC > 90.
Accès direct aux convertisseurs et platines LED assurant l ' installation et l ' entretien sans outil.
50 000 heures de fonctionnement avec une utilisation à 90 % de la puissance( L90B10 à 25 ° C et max. Medium-Power). 5 ans de garantie sur tous les modules LED et convertisseurs LED.
Voir les différentes options
|
OPTIONAL
ALTERNATIVE COLOUR TEMPERATURES: 2200K / 3500K / 6500K
|
LEDS WITH HIGHER CRI Ra > 90 |
||||||||||||||||
