MATRIC-G5 / DIRECT / MICROPRISMATIC
150˚
180˚
MATRIC-G5 / DIRECT / WALLWASHER
L2
150˚
120˚
min 70
120˚
L1
L2
LUMEN/WATT
CODE
150˚
KG
180˚
L2
150˚
120˚
min 70
120˚
LED - LOW POWER
90˚
90˚
150
300
60˚
60˚
450
600
30˚
0˚
30˚
max
1500
82
82
600 570 1535lm/17W* LG5AEE-###E-L600-YS 2,6
890 875 2303lm/23W* LG5AEE-###E-L890-YS 3,0
1182 1170 3071lm/30W* LG5AEE-###E-L1182-YS 3,6
1475 1460 3893lm/36W* LG5AEE-###E-L1475-YS 4,2
1765 1750 4607lm/42W* LG5AEE-###E-L1765-YS 5,6
2350 2335 6143lm/56W* LG5AEE-###E-L2350-YS 6,8
2930 2915 7678m/69W* LG5AEE-###E-L2930-YS 8,3
2235lm/23W* LG5AEE-###M-L600-YS 2,6
600
570
L2
LUMEN/WATT
CODE
KG
LED - MEDIUM POWER
90˚
90˚
140
280
60˚
30˚
420
560
0˚
60˚
30˚
max
1500
82
82
LED - MEDIUM POWER
L1
L1
890 875 3353lm/34W* LG5AEE-###M-L890-YS 3,0
1182 1170 4470lm/44W* LG5AEE-###M-L1182-YS 3,6
1475 1460 5587lm/54W* LG5AEE-###M-L1475-YS 4,2
1765 1750 6705lm/64W* LG5AEE-###M-L1765-YS 5,6
2350 2335 8940lm/85W* LG5AEE-###M-L2350-YS 6,8
2930 2915 11176lm/106W* LG5AEE-###M-L2930-YS 8,3
600 570 773lm/12W* LG5GEE-###M-L600-YS 3,1
890 875 1160lm/17W* LG5GEE-###M-L890-YS 3,9
1182 1170 1550lm/22W* LG5GEE-###M-L1182-YS 4,8
1475 1460 1932lm/26W* LG5GEE-###M-L1475-YS 5,7
1765 1750 2320lm/31W* LG5GEE-###M-L1765-YS 7,3
2350 2335 3100lm/40W* LG5GEE-###M-L2350-YS 9,1
2930 2915 3865lm/49W* LG5GEE-###M-L2930-YS 11,3
E: NON DIMMABLE, D: DIM 1-10V, L: DIM DALI, H: TOUCH-DIM
CONTROL
L1
830 : 3000K, 840 : 4000K
LED COLOUR TEMPERATURE ###
*L e u c h t e n l i c h t s t r o m b e i 4 0 0 0 K
|
Luminaire luminous flux at 40 0 0K
|
Flux de luminaire à 40 0 0K
FLUORESCENT
1182 1162 T5 1x28/54W LG5AEET-128/54-YS 3,5
1182 1162 T5 2x28/54W LG5AEET-228/54-YS 3,6
1486 1466 T5 1x35/49/80W LG5AEET-135/49/80-YS 4,0
1486 1466 T5 2x3
