Lightnet Lighting Catalogue by SKIALIGHT SKIALIGHT | Page 122

AIRTIME-P3 / DIRECT-INDIRECT / MICROPRISMATIC
AIRTIME-P3/G3
150˚
180˚
150˚
120˚
90˚
L1
min 70
120˚
90˚
115
230
60˚
60˚
345
460
30˚
0˚
30˚
max
1500
CODE CODE LED - LOW POWER
LUMEN/WATT
SILVER WHITE
KG
874 2863lm/31W* EP3VSE-###E-L874-YS EP3VWE-###E-L874-YW 1160 3817lm/39W* EP3VSE-###E-L1160-YS EP3VWE-###E-L1160-YW 7,5
1440 4772lm/48W* EP3VSE-###E-L1440-YS EP3VWE-###E-L1440-YW 8,5
6,5
6,5
LED - MEDIUM POWER
22
290
L1
874 3928lm/42W* EP3VSE-###M-L900-YS EP3VWE-###M-L900-YW 1160 5237lm/55W* EP3VSE-###M-L1200-YS EP3VWE-###M-L1200-YW 7,5
1440 6547lm/67W* EP3VSE-###M-L1500-YS EP3VWE-###M-L1500-YW 8,5
E: NON DIMMABLE, L: DIM DALI
CONTROL
830 : 3000K, 840 : 4000K
LED COLOUR TEMPERATURE ###
*L e u c h t e n l i c h t s t r o m b e i 4 0 0 0 K
|
Luminaire luminous flux at 40 0 0K
|
Flux de luminaire à 40 0 0K
AIRTIME-G3 / DIRECT / MICROPRISMATIC
150˚
180˚
150˚
120˚
L1
min 70
120˚
LUMEN/WATT
LED - LOW POWER
90˚
90˚
115
230
60˚
60˚
345
460
30˚
0˚
30˚
max
1500
CODE CODE
SILVER WHITE
KG
874 1892lm/21W* EG3VSE-###E-L874-YS EG3VWE-###E-L874-YW 1160 2522lm/27W* EG3VSE-###E-L1160-YS EG3VWE-###E-L1160-YW
6,0
7,0
1440 3153lm/33W* EG3VSE-###E-L1440-YS EG3VWE-###E-L1440-YW 8,0
6,0
LED - MEDIUM POWER
22
290
L1
874 2607lm/29W* EG3VSE-###M-L900-YS EG3VWE-###M-L900-YW 1160 3476lm/37W* EG3VSE-###M-L1200-YS EG3VWE-###M-L1200-YW 7,0
1440 4345lm/46W* EG3VSE-###M-L1500-YS EG3VWE-###M-L1500-YW 8,0
CONTROL E: NON DIMMABLE, L: DIM DALI
LED COLOUR TEMPERATURE ### 830 : 3000K, 840 : 4000K
*L e u c h t e n l i c h t s t r o m b e i 4 0 0 0 K
|
Luminaire luminous flux at 40 0 0K
|
Flux de luminaire à 40 0 0K
243
DE EN FR
LED-Pendelleuchte, direkt-indirekt (-P3) oder rein
direktstrahlend (-G3). Microprismenoptik aus Spe-
zialacrylglas bildschirmarbeitsplatztauglich nach
EN 12464-1 (UGR<19) mit perfekt homogener
Auflösung der Lichtpunkte. LED pendant luminaire with direct-indirect (-P3)
or direct only (-G3) light distribution. Micropris-
matic screen for glare-free illumination according
to EN 12464-1 (UGR<19) and perfect uniform illumi-
nation. Superflacher Leuchtenkörper mit integriertem Kon-
verter aus Aluminium-Strangpress-Profil. Oberflä-
che in Strukturlack matt weiß (RAL9003) oder matt
silber (RAL9006). Optional weitere Farben (s. Ober-
flächenübersicht). Slimline luminaire body with integrated driver
made of aluminium-profile. Surface matt white
(RAL9003) or mat
