P9R CORE LEP
1000 lm 1 1300 m 1
PRODUCT VIDEO
01 - Laser Excited Phosphor Technology creates a highly focused white light with an extreme beam range
02 - White and red light for homogeneous illumination at close range
03 - Intuitive mode switch for direct access to light functions
04 - Hard-anodized housing material for added protection against wear and corrosion , high dust and water protection ( IP68 )
05 - Convenient charging of the battery via Magnetic Charge System
Laser as a light source : Instead of using an LED , blue laser light is directed at a phosphor-coated plate and transformed into white light which then travels through two lenses , resulting in a white light that is highly focused and has an extreme range .
LEP / LED
P9R CORE LEP
LEP- / LED-Configuration 1x Laserdiode ( LEP ), 1x COB LED ( Red + White ) Light Functions
Boost / Power / Mid Power / Low Power Luminous Flux 1 ( lm ) LEP : 400 / 250 / - / 75 COB : 1000 / 550 / 300 / 150 Beam Distance 1 ( m ) LEP : 1300 / 1000 / - / 550 COB : 40 / 30 / 20 / 15 Run Time 1 ( h ) LEP : - / 4 / - / 10 COB : - / 4 / 8 / 20 Color Temperatur ( K ) LEP : 6000 - 8000 COB : 5700-6700 Color Rendering Index ( CRI ) LEP : 65 COB : 80
BATTERY AND CASE
Battery 1x 21700 Li-ion Akku 3.7V Battery Capacity2 ( Wh / mAh ) 17.76 / 4800 IP Level Rechargeable
IP68
Ja Charging Time 5 ( min ) 270 Fallhöhe ( m ) 2
SIZE AND WEIGHT
Length – defocused ( mm ) 176 Head diameter ( mm ) 41 Weight incl . Battery ( g / oz ) 269 / 9.49
TECHNOLOGIES
Laser Excited Phosphor Techn . Magnetic Charge System More Features
PACKAGING
Temperature Control System , Magnetic Charge System , Dimmable , Red Light , Transportation Lock , Flicker Free , Backup Mode , Mode Switch
Item No . Box / GTIN 502987 / 4058205034647 Content Box
OPTIONALES ZUBEHÖR
More Accessories on page 74
1 Battery Pack , Wrist Strap , Pouch , Magnetic Charging Cable
502271 USB Adapter 2.4A
1-11
Information on page 88 19
