AL10R WORK
The lantern is equipped with three individually switchable light panels ( 360 °, 240 °, 120 °) to help save energy and avoid light loss . By switching one or two panels off , the AL10R Work can easily be adapted to any situation – for instance , when it is placed in a corner .
Fig . with diffuser
Fig . with diffuser and cable
LED
Light Functions
5 Brightness levels
Luminous Flux 1 ( lm ) 6300 / 5100 / 3600 / 1800 / 750 Run Time 1 ( h ) 1 / 1.25 / 2 / 4 / 9.5 Color Temperatur ( K ) 3000-6500 ( 5-stage adjustable ) Color Rendering Index ( CRI ) ≥ 80
BATTERY AND CASE
Battery Li-ion Battery ( internal ) Battery Capacity2 ( Wh / mAh ) 7.2 / 4700 Rechargeable
Ja Charging Time 5 ( min ) 390 IP Level
SIZE AND WEIGHT
IP67
B / H / T ( mm ) 110 x 390 x 110 Weight incl . Battery ( g / oz ) 1397 / 49.3
TECHNOLOGIES
Temperature Control Cooling Technology Hybrid Power Tunable White
More Features Charge Indicator , Battery Indicator , Transportation Lock , Dimmable , Memory Function , Chemical Resistant
PACKAGING
Item no . Hard Case / GTIN 5029137 / 4058205033268 Contents Hard Case
OPTIONAL ACCESSORIES
Power Supply , Diffuser
503018 Controller
Accessories
on page 74 503016 Extension cable 5 m 10
1-11
Information on page 88
