True laser power in your hands! There is no need to decide between a highly focused white light with an extreme beam range or a homogeneous illumination at close range. Our new P9R Core LEP offers both and is ideal for search and rescue teams, members of the maritime sector as well as hunters and anglers.
01 Laser Excited Phosphor Technology creates a highly focused white light with an extreme beam range
02 White and red light for homogeneous illumination at close range
03 Intuitive mode switch for direct access to light functions
04 Hard-anodized housing material for added protection against wear and corrosion, high dust and water protection( IP68) 05 Convenient charging of the battery via Magnetic Charge System
LED
LED Configuration 1x Laserdiode( LEP), 1x COB LED( White Light) Light Functions
Boost / Power / Mid Power / Low Power Luminous Flux 1( lm) LEP: 400 / 250 /- / 75 COB: 1000 / 550 / 300 / 150 Beam Distance 1( m) LEP: 1300 / 1000 /- / 550 COB: 40 / 30 / 20 / 15 Run Time 1( h) LEP:- / 4 /- / 10 COB:- / 4 / 8 / 20 Color Temperature( K) LEP: 6000- 8000 COB: 5700-6700 Color Rendering Index( CRI) LEP: 65 COB: 80
BATTERY AND CASE
Battery 1x 21700 Li-ion Battery 3.7V Battery Capacity2( Wh / mAh) 17.76 / 4800 IP Level Rechargeable
IP68
JaYes Charging Time 5( min) 270 Drop Height( m) 2
SIZE AND WEIGHT
Length – defocused( mm) 176 Head Diameter( mm) 41 Weight incl. Batteries( g) 269
TECHNOLOGIES
Magnetic Charge System LEP Technology Temperature Control More Features
PACKAGING
Laser Excited Phosphor Technology, Mode Switch, Magnetic Charge System, Dimmable, Red Light, Transportation Lock, Flicker Free, Backup Mode
Item no. Box / GTIN 502987 / 4058205034647 Content Box
OPTIONAL ACCESSORIES
More Accessories on page 74
1 Battery Pack, Lanyard, Pouch, Magnetic Charging Cable
502251 Lamp Adapter Type D 501033 Magnetic Mount
1-9
Information on page 88 29
