MILLING
CUTTERS APKT
Ap
d
90°
D
L1
L
END MILL - APKT 060204 PDTR** / APKT 0602-HF** / APKW 0602-HF**
DESIGNATION
LT 752 C-W-D010/2
LT 752 C-W-D012/3
LT 752 CL-W-D012/3*
LT 752 C-W-D016/4
LT 752 CL-W-D016/3*
LT 752 C-W-D020/5
LT 752 CL-W-D020/4*
LT 752 C-W-D025/7
LT 752 CL-W-D025/6*
D D1 HF d
10
12
12
16
16
20
20
25
25 4.7
6.7
6.7
10.7
10.7
14.7
14.7
19.7
19.7 10
12
10
16
14
20
18
20
20
L
L1
72
16
80
26
120 13.5
90
32
160 13.5
100 40
200 13.5
120 40
220 15
Ap HF Ap 90 o
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
*Available Q3 2017
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
α HF α 90 o
Z
2
3
3
4
3
5
4
7
6
CATALOG #
3.25 3
2.5 2.2
2.5 2.2
2
1.5
2
1.5
1.25 1.15
1.25 1.15
1
0.9
1
0.9 M2003098
SCREW
SCREW DRIVER HANDLE
PRESET ADAPTER 0.4NM
TORX PLUS BIT M2001640
M2002922
M2002923
M2003064
M2003099
M2003078
M2003100
M2003105
M2003101
M2003080
M2003102
M2003081
END MILL - APKT 100308 PDTR / APKT 100304 PDTR / APKT 100312 PDTR / APKT 100316 PDTR
D d L L1 Ap Z LT 741 C-W-D016/2 16 16 100 25 9 2 12 M2002806
LT 741 CL-W-D016/2 16 16 150 35 9 2 α 12 M2002817
LT 741 C-W-D018/2 18 20 100 30 9 2 12 M2002807
LT 741 C-W-D020/3 20 20 100 30 9 3 7 M2002808
LT 741 CL-W-D020/3 20 20 150 35 9 3 7 M2002818
LT 741 C-W-D022/3 22 20 100 30 9 3 7 M2002809
LT 741 C-W-D025/3 25 25 120 30 9 3 5 M2002810
LT 741 C-W-D025/4 25 25 120 30 9 4 5 M2002811
LT 741 CL-W-D025/4 25 25 200 40 9 4 5 M2002819
LT 741 C-W-D028/4 28 25 120 30 9 4 2 M2002812
LT 741 C-W-D030/4 30 25 120 30 9 4 2 M2002813
LT 741 W-W-D032/5 32 32 120 30 9 5 3 M2002814
LT 741 WL-W-D032/4 32 32 200 40 9 4 3 M2002820
DESIGNATION
SCREW
KEY
CATALOG #
M2002181
M2000601
** Due to the small size of these inserts, using a pre-set torque screw driver (0.4Nm) at all times is recommended. It is also
recommended that during mounting, the insert should be held in place with a finger.
