MILLING
CUTTERS RD..
d
L
Ap
D1
D
SHELL MILL - RD.. 1204 M0
D D1 d L Ap Z LT 120 M-W-D040/4 40 28 16 40 6 4 7.0 M2000691
LT 120 M-W-D050/4 50 38 22 50 6 4 α 5.0 M2001780
LT 120 M-W-D063/5 63 51 22 50 6 5 3.5 M2000689
LT 120 M-W-D080/6 80 68 27 50 6 6 2.5 M2000690
LT 120 M-W-D100/7 100 88 32 50 6 7 2.0 M2000688
DESIGNATION
SCREW
KEY
CATALOG #
M2000597
M2000602
SHELL MILL - RD.. 1604 M0
D D1 d L Ap Z LT 160 M-W-D050/4 50 34 22 50 8 4 5.0 M2003331
LT 160 M-W-D063/5
LT 160 M-W-D080/6
LT 160 M-W-D100/7 63
80
100 47
64
84 22
27
32 50
50
50 8
8
8 5
6
7 α 3.5
2.5
2.0 M2003332
M2003333
M2003334
LT 160 M-W-D125/8 125 109 40 63 8 8 1.0 M2003335
DESIGNATION
SCREW
KEY
CATALOG #
M2000599
M2000603
