MILLING
CUTTERS APKT / APKW
Ap
d
D1 D
L1
L
END MILL - APKT 060204** / APKT 0602-HF** / APKW 0602-HF**
DESIGNATION
LT 752 C-W-D010/2
LT 752 C-W-D012/3
LT 752 CL-W-D012/3*
LT 752 C-W-D016/4
LT 752 CL-W-D016/3*
LT 752 C-W-D020/5
LT 752 CL-W-D020/4*
LT 752 C-W-D025/7
LT 752 CL-W-D025/6*
D D1 HF d
10
12
12
16
16
20
20
25
25 4.7
6.7
6.7
10.7
10.7
14.7
14.7
19.7
19.7 10
12
10
16
14
20
18
20
20
L
L1
Ap HF Ap 90 o
72
16 0.5
80
26 0.5
120 13.5 0.5
90
32 0.5
160 13.5 0.5
100 40 0.5
200 13.5 0.5
120 40 0.5
220 15 0.5
* Available Q3 2017
Z
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
5.2
2
3
3
4
3
5
4
7
6
α HF α 90 o
3.25
2.5
2.5
2.0
2.0
1.25
1.25
1.0
1.0
CATALOG #
3.0
2.2
2.2
1.5
1.5
1.15
1.15
0.9
0.9 M2003098
M2003099
M2003078
M2003100
M2003105
M2003101
M2003080
M2003102
M2003081
SCREW
SCREW DRIVER HANDLE
PRESET ADAPTER 0.4NM
TORX PLUS BIT M2001640
M2002922
M2002923
M2003064
Ap
d
D1
D
L1
SCREW COUPLING - APKT 060204** / APKT 0602-HF** / APKW 0602-HF**
DESIGNATION
LT 752 S-W-D010/2*
LT 752 S-W-D012/3*
LT 752 S-W-D016/4*
LT 752 S-W-D020/5*
LT 752 S-W-D025/7*
LT 752 S-W-D032/8*
* Available Q3 2017
D D1 HF d L1
10
12
16
20
25
32 4.7
6.7
10.7
14.7
19.7
26.7 M6
M6
M8
M10
M12
M16 19
19
22
25
25
30
Ap HF Ap 90 o
0.5
0.5
0.5
0.5
0.5
0.5
5.2
5.2
5.2
5.2
5.2
5.2
Z
2
3
4
5
7
8
α HF
α 90 o
CATALOG #
3.0
2.2
1.5
1.15
0.9
0.7 M2003087
M2003088
M2003089
M2003090
M2003091
M2003094
SCREW
SCREW DRIVER HANDLE
PRESET ADAPTER 0.4NM
TORX PLUS BIT M2001640
M2002922
M2002923
M2003064
3.25
2.5
2.0
1.25
1.0
0.7
** Due to the small size of these inserts, using a pre-set torque screw driver (0.4Nm) at all times is recommended. It is also
recommended that during mounting, the insert should be held in place with a finger.
