MILLING
CUTTERS ADKT
d
D
Ap
90°
L1
L
END MILL - ADKT 1505
α
D d L L1 Ap Z LT 790 W-W-D025/2* 25 25 100 44 15 2 5.0 M2001613
LT 790 W-W-D032/3* 32 32 110 50 15 3 3.0 M2001503
DESIGNATION
*On Request
SCREW
KEY
CATALOG #
M2000597
M2000602
d
L
90° Ap
D
SHELL MILL - ADKT 1505
D d L Ap Z LT 790 M-W-D040/4* 40 16 40 15 4 2.5 M2001615
LT 790 M-W-D050/5* 50 22 40 15 5 α 2.2 M2001504
LT 790 M-W-D063/6* 63 22 40 15 6 1.8 M2001616
LT 790 M-W-D080/7* 80 27 50 15 7 1.4 M2001617
DESIGNATION
* On Request
SCREW
KEY
CATALOG #
M2000597
M2000602
101
