VHM NC Maschinenreibahlen H7 für Durchgangsbohrungen
Solid carbide NC machine reamers H7 for through holes
Carbure Alésoir NC machine H7 trou de passage
H 7
AlTiCrN
HX
≤ 65
HRC
12
12. 70
Bestell Nr.
Order no.
Référence d 1 H7 l 2 l 3 l 1 d 2 Zähne
Teeth
dent
RS600.0095 0.95 6.00 20.00 60.00 3.00 4
RS600.0096 0.96 6.00 20.00 60.00 3.00 4
RS600.0097 0.97 6.00 20.00 60.00 3.00 4
RS600.0098 0.98 6.00 20.00 60.00 3.00 4
RS600.0099 0.99 6.00 20.00 60.00 3.00 4
RS600.0100 1.00 6.00 20.00 60.00 3.00 4
RS600.0101 1.01 6.00 20.00 60.00 3.00 4
RS600.0102 1.02 6.00 20.00 60.00 3.00 4
RS600.0103 1.03 6.00 20.00 60.00 3.00 4
RS600.0104 1.04 6.00 20.00 60.00 3.00 4
RS600.0105 1.05 6.00 20.00 60.00 3.00 4
RS600.0195 1.95 15.00 30.00 60.00 3.00 4
RS600.0196 1.96 15.00 30.00 60.00 3.00 4
RS600.0197 1.97 15.00 30.00 60.00 3.00 4
RS600.0198 1.98 15.00 30.00 60.00 3.00 4
RS600.0199 1.99 15.00 30.00 60.00 3.00 4
RS600.0200 2.00 15.00 30.00 60.00 3.00 4
RS600.0201 2.01 15.00 30.00 60.00 3.00 4
RS600.0202 2.02 15.00 30.00 60.00 3.00 4
RS600.0203 2.03 15.00 30.00 60.00 3.00 4
RS600.0204 2.04 15.00 30.00 60.00 3.00 4
RS600.0205 2.05 15.00 30.00 60.00 3.00 4
RS600.0295 2.95 15.00 30.00 60.00 3.00 4
RS600.0296 2.96 15.00 30.00 60.00 3.00 4
RS600.0297 2.97 15.00 30.00 60.00 3.00 4
RS600.0298 2.98 15.00 30.00 60.00 3.00 4
RS600.0299 2.99 15.00 30.00 60.00 3.00 4
RS600.0300 3.00 15.00 30.00 60.00 3.00 4
RS600.0301 3.01 15.00 30.00 60.00 3.00 4
RS600.0302 3.02 15.00 30.00 60.00 3.00 4
RS600.0303 3.03 15.00 30.00 60.00 3.00 4
KEMMLER
www.klte.cz
Form
A
