Multi Cone Post Insulators other types of insulators used for similar applications.
Cap and pin type post insulators are divided into two main groups, nonstacking and stacking units. Single units are available for service voltage upto 36kV and multi-unit stacks are available for service voltage upto 245kV.
Specifications
• Rating: Up to 36 kV and up to 245 kV with multi units
Cap and pin type insulators are designed mainly to support disconnecting switches, busbars, conductors, and equipment for substations. They are capable of being stressed in tension, compression, flexion, torsion and combined stresses upto the specified limits. These insulators are more economical than
• Mechanical strength: up to 32 kN
• Creepage distance: 1050 mm( single unit)
• Applicable standards: IS, IEC, ANSI specifications www. adityabirlainsulators. com
Air Circuit Breaker
WiNmaster circuit breakers use the latest technology to enhance performance and safety. Compact yet offering various connections for ease of installation snap on site fit accessories, enhanced life and intuitive operation makes them a very user friendly range of circuit breaker for any application.
The complete range of WiNmaster ACB confirms to the latest IEC 60947-2 / IS 13947-2 standard.
WiNmaster ACB simplifies the design of switchboard and standardizes the installation of the products.
All accessories are common for entire range and now can be easily fitted from the front.
• Uses the latest technology to enhance performance and safety
• Simplifies the design of switchboard and standardizes the installation of the products
• Used in industries and power systems
• Uninterrupted service throughout the product life
• Total solution for modern day requirement for measurement, analysis and communications
RANGE:
• Rating: 630A ~ 4000A
• Poles: 3P & 4P
• Frame Size: 2000AF & 4000AF
• Version: Fixed – Manual & Electrical and Drawout – Manual & Electrical
FEATURES:
• Breaking capacity Ics = Icu = Icw up to 65kA
• Common height & depth across the range
• Common accessories across the range
• Modular construction with most compact dimensions
• High mechanical & electrical operating Life
• Intelligent micropro releases with communication protocol( modbus / profibus) RS485
• Multiple horizontal / vertical terminal connection option www. cselectric. co. in
