product spotlight
Components dedicated to hydraulics New HCX-PT and HCV-E column level indicators
One of the main objectives of Elesa + Ganter is to offer a broad range of solutions to meet the specific needs of different industries .
Elesa + Ganter accessories for hydraulic systems set up a wide and versatile range . A market niche that requires reliable components that can operate under unfavorable environmental conditions , such as high temperatures or atmospheric and chemical agents . For this reason , all components must be made of materials ensuring high and unchanging performance over time .
In response to the needs of this sector , Elesa + Ganter has introduced two new column level indicators : HCX-PT and HCV-E .
Both level indicators are made of transparent technopolymer with white lacquered aluminium contrast screen , housed in the external rear slot , ensuring the best protection from direct contact with fluid .
HCX-PT column level indicator is distinguished by the SUPERtechnopolymer protection frame ( material that can provide mechanical and thermal properties far superior to the
traditional polymers ) that absorbs accidental shocks transmitting them directly onto the wall of the reservoir . The indicator is available with or without incorporated thermometer , screws , nuts and washers made of zinc-plated steel , AISI 303 stainless steel or SUPER-technopolymer . In addition , special openings in the protection frame provide maximum fluid level visibility even from side positions .
HCV-E column level indicator , in addition to the visual control , generates an electric signal when the oil level drops to a minimum . Standard executions are available with a built-in relay with two conductors ( NO and NC versions ) at the output or three connectors ( SW version ).
Thanks to the side output of the connector , HCV-E level indicator allows to minimize the level of intervention of the sensor because assembled at the nearest position to the minimum fluid level ( 63 mm from the back of the tank ). The swivelling connector with front or axial output guarantees protection against water jets , ensuring IP65 protection class according to IEC 529 .
Products technical data sheets , along with drawings and tables with codes and dimensions , are available on our website www . elesa-ganter . in
