which produced two distinct pulses at a repetition rate of 1.612 kHz. Upon increasing the pump energy density to 50 J / cm 2, the system generated up to 22 pulses per burst at intra-burst repetition rate( f rep) of7.142kHz. Forthe longest cavity length studied( 465 mm), a higher threshold of 40 J / cm 2 was observed, with five pulses produced at 1.922 kHz at threshold and 17 pulses at 6.25 kHz when pumped at 50 J / cm 2.
Moreover, the temporal dynamics of dual pulse train generation in the passive Q-switched Nd: YAG laser were characterized, with a measured inter-train interval of 13.12 ms and individual train durations of approximately 250 ls. The pulse width within each train was found to be 45 ns, featuring a peak amplitude of 56 mV.
Finally, green light generation at 532 nm was successfully achieved through intracavity second-harmonic generation employing a KTP nonlinear crystal within the passive Q-switched laser cavity. The optimized frequency-doubled output exhibited pulse durations on the order of 6 ns, peak voltages reaching 65.2 mV, an intra-burst repetition rate( f rep) of 3.846 kHz, and a pulse period of 6 ns, reflecting efficient coherent nonlinear conversion in the KTP crystal.
Funding
This research was supported by Shahid Chamran University of Ahvaz, Iran under the grant number SCU. SP1401.259.
Conflicts of interest
Theauthorsdeclare thattherearenoconflicts of interest related to this work.
Data availability statement
The data that support the findings of this study are available from the corresponding author upon reasonable request.
Author contribution statement
Hossein Albaji: Experimentation, Data Curation, Writing – Original Draft.
Mohammad Sabaeian: Project Administration, Funding Acquisition, Methodology, Supervision, Conceptualization.
Hajar Alirezaei: Co-supervision, Experimentation, Writing – Review & Editing.
References
1 Tang J, Bai Z, Zhang D, Qi Y, Ding J, Wang Y, Lu Z, Advances in all-solid-state passively Q-switched lasers based on Cr 4 +: YAG saturable absorber, Photonics 8( 4), 93( 2021). https:// doi. org / 10.3390 / photonics8040093.
2 Almabouada F, Aiadi K. E, Experimental study of a flashlamp pumped passively Q-switched Nd: YAG laser using Cr 4 +: YAG saturable absorber, Int. J. Eng. 31( 11), 1870 – 1875( 2018).
3 Jazia M. E, Soltanolkotabi M, Baghi M. D, Hajimahmoodzadeh M, Investigation of effective parameters on pulsed Nd: YAG passive Q-switched laser, Iran. J. Opt. Photon. 5( 1), 41( 2011).
4 Huang Y, Huang Y, Chen Y.-F, Efficient high-energy passively Q-switched Nd: YAG / Cr 4 +: YAG laser with a convex – concave resonator, Adv. Solid State Lasers, Optica Publ. Group, p. ATu2A. 51( 2014). https:// doi. org / 10.1364 / ASSL. 2014. ATu2A. 51
5 Maleki A et al., 57 mJ with 10 ns passively Q-switched diodepumped Nd: YAG laser using Cr 4 +: YAG crystal, Opt. Quantum Electron. 48, 1( 2016). https:// doi. org / 10.1007 / s11082-015-0332-x.
6 Wang Z et al., Passively Q-switched dual-wavelength laser output of LD-end-pumped ceramic Nd: YAG laser, Opt. Express 17, 12076( 2009). https:// doi. org / 10.1364 / OE. 17. 012076. 7 Koechner W, Laser Amplifier, in Solid-State Laser Engineering, 6th edn.( Springer, New York, 2006), pp. 156 – 209
8 Kiselev AV, Pankov M A, Q-switched mode in laser ceramics with Cr 4 + for technological surface cleaning, IOP Conf. Ser.: Mater. Sci. Eng. 896, 012134( 2020). https:// doi. org / 10.1088 / 1757-899X / 896 / 1 / 012134. 9 Dumitrache C, Vasile N. T, Croitoru G, Pavel N, Laserinduced ignition of methane – air mixtures by a four-beam, pulse-burst mode passively Q-switched Nd: YAG / Cr 4 +: YAG laser, Results Phys. 42, 105958( 2022). https:// doi. org / 10.1016 / j. rinp. 2022.105958.
10 Li X et al., A compact pulse-burst laser with YAG / Nd: YAG / Cr ++: YAG composite crystal, Optik 136, 107( 2017). https:// doi. org / 10.1016 / j. ijleo. 2017.02.022.
11 Huang J, Zhang Y, Chen J, Yang M, modeling of ultrafast phase change processes in a thin metal film irradiated by femtosecond laser pulse trains, J. Heat Transf. 133, 031003( 2011). https:// doi. org / 10.1115 / 1.4002444.
12 Ma Y et al., A novel miniaturized passively Q-switched pulse-burst laser for engine ignition, Opt. Express 22, 24655( 2014). https:// doi. org / 10.1364 / OE. 22.024655.
13 Förster DJ, Jäggi B, Michalowski A, Neuenschwander B, Review on experimental and theoretical investigations of ultra-short pulsed laser ablation of metals with burst pulses, Materials 14( 12), 3331( 2021). https:// doi. org / 10.3390 / ma14123331.
14 Bourdon P, Planchat C, Fleury D, Le Gouët J, Gustave F, Dolfi-Bouteyre A, Lombard L, Durécu A, Jacqmin H, Passively cooled Cr: YAG Q-switched Yb: YAG micro-laser delivering continuously tunable high repetition rate bursts of short pulses, Proc. SPIE 10896, 72( 2019). https:// doi. org / 10.1117 / 12.2509413.
15 Harris W, Den Hartog D, Hurst N, Initial operation of a pulse-burst laser system for high-repetition-rate Thomson scattering, Rev. Sci. Instrum. 81, 10( 2010). https:// doi. org / 10.1063 / 1.3466901.
16 Masada G, Yoshida K, Suzuki Y, second harmonic generation at 532 nm using an external cavity with a periodically poled KTiOPO 4 crystal, Tamagawa Univ. Quantum ICT Res. Inst. Bull. 13, 35( 2023).
17 Xu D et al., 104 W high stability green laser generation by using diode laser pumped intracavity frequency-doubling Q- switched composite ceramic Nd: YAG laser, Opt. Express 15, 3991( 2007). https:// doi. org / 10.1364 / OE. 15.003991. 18 van Deril HM, Laser Dynamics( Cambridge University
Press, Cambridge, 2004).
19 Park D, Jeong J, Yu TJ, Optimization of the pulse width and injection time in a double-pass laser amplifier, High Power Laser Sci. Eng. 6, e60( 2018). https:// doi. org / 10.1017 / hpl. 2018.55.
