NLOS scene. This reduces performance variations that depend on the target position in comparison to single illumination schemes. Second, increased variation of illumination and detection pairs further confine the feasible target position as explicitly elaborated for the ellipsoid based backprojection reconstruction.
For single target localization scenarios, LoG based edge filtering of the reconstruction as commonly done in FBP NLOS imaging does not adequately counteract pulsewidth-induced temporal smearing that enlarges the feasible target region. Preprocessing the temporal measurement data by explicitly managing pulse widths outperforms filtering of the reconstruction result. Matched filtering was used to incorporate all signal photons received, posing an additional advantage over spatial edge detection that relies only on the first part of the pulse form. This fits in with the endeavor to develop a photon-efficient NLOS system, to address the limited emissions in eye-safe operation.
The presented system can be developed further into a hybrid LiDAR-NLOS system with an additional spatially broadened laser source that illuminates the detector’ s field of view, known as solid-state Flash-LiDAR. A direct ToF measurement can determine the orientation and the system’ s position relative to the relay wall, which is necessary to process the NLOS measurement. One application of this eye-safe compact hybrid system could be the localization of persons beyond the line of sight on an upper floor through a window, using the ceiling as the relay wall.
Funding This research received no external funding.
Conflicts of interest The authors have nothing to disclose.
Data availability statement
The original contributions presented in this study are included in the article. Further inquiries can be directed to the corresponding author.
Author contribution statement
Conceptualization, K. A. and M. L.; Methodology, K. A. and J. K.; Software, K. A. and J. K.; Validation K. A., J. K. and M. L.; Investigation, K. A.; Writing – Original Draft Preparation, K. A. and J. K.; Writing – Review & Editing, J. K., M. L. and A. G; Visualization, K. A. and J. K.; Supervision, M. L. and A. G.
All authors have read and agreed to the submitted version of the manuscript.
References
1 Klein J, Peters C, Martín J, Laurenzis M, Hullin MB, Tracking objects outside the line of sight using 2D intensity images, Sci. Rep. 6, 32491( 2016). https:// doi. org / 10.1038 / srep32491.
2 Musarra G, Lyons A, Conca E, Villa F, Zappa F, Altmann Y, Faccio D, in Imaging and Applied Optics 2019( COSI, IS,
MATH, pcAOP)( OSA, Washington, D. C.), IM2B. 5. https:// doi. org / 10.1364 / ISA. 2019. IM2B. 5.
3 Lindell DB, Wetzstein G, Koltun V, in 2019 IEEE / CVF Conference on Computer Vision and Pattern Recognition( CVPR)( IEEE, 2019), p. 6773. https:// doi. org / 10.1109 / CVPR. 2019.00694.
4 Maeda T, Wang Y, Raskar R, Kadambi A, in 2019 IEEE International Conference on Computational Photography( ICCP)( IEEE, 2019), p. 1. https:// doi. org / 10.1109 / ICCPHOT. 2019.8747343.
5 Wu C, Liu J, Huang X, Li ZPC, Yu JT, Ye J, Zhang Q, Zhang X, Dou VK, Goyal F, Xu JWP, Non-line-of-sight imaging over 1.43 km, Proc. Natl. Acad. Sci. USA 118( 2021). https:// doi. org / 10.1073 / pnas. 2024468118.
6 Zhang W, Zhu S, Chen L, Bai L, Lam EY, Guo E, Han J, High-resolution and real-time non-line-of-sight imaging based on spatial correlation, Opt. Lasers Eng. 193, 109100( 2025). https:// doi. org / 10.1016 / j. optlaseng. 2025.109100.
7 Nam JH, Brandt E, Bauer S, Liu X, Renna M, Tosi A, Sifakis E, Velten A, Low-latency time-of-flight non-line-of-sight imaging at 5 frames per second, Nat. Commun. 12, 6526( 2021). https:// doi. org / 10.1038 / s41467-021-26721-x.
8 O’ Toole M, Lindell DB, Wetzstein G, Confocal non-line-ofsight imaging based on the light-cone transform, Nature 555, 338( 2018). https:// doi. org / 10.1038 / nature25489.
9 Faccio D, Velten A, Wetzstein G, Non-line-of-sight imaging, Nat. Rev. Phys. 2, 318( 2020). https:// doi. org / 10.1038 / s42254-020-0174-8.
10 Liu X, Wang J, Xiao L, Shi Z, Fu X, Qiu L, Non-line-of-sight imaging with arbitrary illumination and detection pattern, Nat. Commun. 14, 3230( 2023). https:// doi. org / 10.1038 / s41467-023-38898-4.
11 Wang K, Zhang M, Shi Y, in Fourth International Computational Imaging Conference( CITA 2024), edited by X. Shao( SPIE, 2024), p. 40. https:// doi. org / 10.1117 / 12.3055473.
12 Zhao Z, Zhang Q, Li X, Guo Y, Pu M, Zhang F, Guo H, Wang Z, Fan Y, Xu M, Luo X, High-resolution non-line-ofsight imaging based on liquid crystal planar optical elements, Nanophotonics( Berlin, Germany) 13, 2161( 2024). https:// doi. org / 10.1515 / nanoph-2023-0655.
13 Jin C, Tang M, Jia L, Tian X, Yang J, Qiao K, Zhang S, Scannerless non-line-of-sight three dimensional imaging with a 32x32 SPAD array, arXiv preprint arXiv: 2011.05122, 2020.
14 Zhang W, Guo E, Zhu S, Huang C, Chen L, Liu L, Bai L, Lam EY, Han J, Real-time scan-free non-line-of-sight imaging, APL Photon. 9( 2024). https:// doi. org / 10.1063 / 5.0235687.
15 Haase JF, Grollius S, Grosse S, Buchner A, Ligges M, in Photonic Instrumentation Engineering VIII, edited by Y. Soskind, L. E. Busse( SPIE, 2021), p. 20. https:// doi. org / 10.1117 / 12.2578775.
16 Leitel R, Dannberg P, Seise B, Brüning R, Grosse S, Ligges M, in Optical Sensing and Detection VIII, edited by F. Berghmans, I. Zergioti( SPIE, 2024), p. 71. https:// doi. org / 10.1117 / 12.3023124.
17 Liu X, Bauer S, Velten A, Phasor field diffraction based reconstruction for fast non-line-of-sight imaging systems, Nat. Commun. 11, 1645( 2020). https:// doi. org / 10.1038 / s41467-020-15157-4.
18 Lindell DB, Wetzstein G, O’ Toole M, Wave-based non-line-ofsight imaging using fast f-k migration, ACM Trans. Graph. 38, 1( 2019). https:// doi. org / 10.1145 / 3306346.3322937. 19 Zheng Y, Wang W, Zhang C, Zhang Y, Zhang Q, Li L,
Converting non-confocal measurements into semi-confocal
