J. Eur. Opt. Society-Rapid Publ. 22, 12( 2026) 123
The incident light was focused onto a piece of Diptera cuticle at normal incidence using an achromatic 10 objective lens, leading to a beam spot diameter of ca. 30 lm. This lens collected light backscattered by the sample, which was conducted by a beamsplitter through a CP analyser comprising the Fresnel rhomb and a second rotatable polariser. A plane aluminium mirror was used for the measurement calibration.
Supplementary material 3 Figure S2. CP reflectance spectrophotometry was used in order to highlight possible light-polarising effects arising from the pattern observed within Calliphora vicina’ s cuticle that might be associated with a Bouligand structure. Despite the electron micrograph observations, only cross-CP components have significant intensities. Co-CP reflectance spectra that usually contains the signature of Bouligand structures display negligible intensities.
Supplementary material 4 Figure S3. Reflectance spectra of a pseudo-periodic multilayer derived from Calliphora vicina photonic model( Fig. 7) with random thickness deviations of ± 15 nm in the high-contrast layers and ± 5 nm in the low-contrast layers. The resulting calculated spectra were averaged over incidence angles from �5 ° to + 5 °. A broader reflectance peak than the ideal model( Fig. 8a) isobserved, though still narrower than the measured spectrum( Fig. 3a).
Supplementary material 5 CP reflectance was modelled for various incidence angles using a one-dimensional 4 4 matrix method for anisotropic multilayers [ 83 ]. The model comprises a Bouligand structure overlaid by an interferential thin film. The Bouligand structure contained 18 half-pitches of 118 nm, had an average refractive index of 1.56 [ 78 ], and exhibited an in-plane birefringence of 0.018 [ 66 ]. The overlying thin film was modelled as a 180-nm thick isotropic layer with a refractive index of 1.75. All materials were assumed to be non-absorbing.
Supplementary material 6 Figure S4. For comparison, CP reflectance was modelled for a Bouligand structure( 18 half-pitches of 118 nm, an average refractive index of 1.56 [ 78 ], in-plane birefringence of 0.018 [ 66 ]) covered by a 180 nm-thick isotropic film( n = 1.75), calculated for incidence and emergence angles ranging from 0 ° to 75 ° in 15 ° increments in cross-CP configuration( a) and at normal incidence in co- and cross-CP configuration( b). Modelled CP reflectance spectra in( a) appear as broad as the experimental spectra measure from Calliphora vicina( Fig. 3a). The left-left co-CP( LCP-LCP) spectrum exhibits a small peak in the UV range. In the real photonic structure of C. vicina, positional disorder [ 44 ], light absorption, and scattering would likely reduce this co-CP signal to a very weak level.
The supplementary material of this article is available at https:// jeos. edpsciences. org / 10.1051 / jeos / 2025053 / olm.
References
1 Berthier S, La couleur des papillons ou l’ impérative beauté- Propriétés optiques des ailes de papillons( Springer, Paris, 2000). 2 Berthier S, Iridescences, les couleurs physiques des insectes
( Springer, Paris, 2003). 3 Kinoshita S, Structural Colors in the Realm of Nature
( World Scientific Publishing Co, Singapore, 2008).
4 Mouchet SR, Deparis O, Natural Photonics and Bioinspiration( Artech House, London, 2021).
5 Mouchet SR, Vukusic P, Structural colours in lepidopteran scales, Adv. Insect Physiol. 54, 1 – 53( 2018). https:// doi. org / 10.1016 / bs. aiip. 2017.11.002.
6 Seago AE, Brady P, Vigneron JP, Schultz TD, Gold bugs and beyond: a review of iridescence and structural colour mechanisms in beetles( Coleoptera), J. R. Soc. Interface 6, S165 – S184( 2009). https:// doi. org / 10.1098 / rsif. 2008.0354. focus. 7 Vukusic P, Chittka L, Visual signals: color and light production, in The Insects: Structure and Function, edited by R. F. Chapman, 5th edn.( Cambridge University Press, Cambridge, 2013), pp. 793 – 822. https:// doi. org / 10.1017 / CBO9780511818202.026.
8 Mason CW, Structural colors in insects III, J. Phys. Chem. 31, 1856 – 1872( 1927). https:// doi. org / 10.1021 / j150282a008.
9 Fraenkel G, Observations and experiments on the blow-fly( Calliphora erythrocephala) during the first day after emergence, P. Zool. Soc. Lond. 105, 893 – 904( 1935). https:// doi. org / 10.1111 / j. 1469-7998.1935. tb06269. x.
10 Wolfe S, Studies of the development of the imaginal cuticle of Calliphora erythrocephala, Q. J. Microsc. Sci. 95, 67 – 78( 1954). https:// doi. org / 10.1242 / jcs. s3-95.29.67.
11 Martincek I, Pudis D, Satka A, Janigova I, Csomorova K, Cernobila F, Temperature effect on optical properties of the cuticle of Lucilia sericata, Optik 119, 523 – 527( 2008). https:// doi. org / 10.1016 / j. ijleo. 2007.02.009.
12 Cai C, Tihelka E, Pan Y, Yin Z, Jiang R, Xia F, Huang D, Structural colours in diverse Mesozoic insects, Proc. R. Soc. B 287, 20200301( 2020). https:// doi. org / 10.1098 / rspb. 2020.0301.
13 Hou Z, Cai D, Dong R, Structural color in Amber-entombed wasp: A detailed study using NS-FDTD simulations, IEEE Access 12, 57163 – 57171( 2024). https:// doi. org / 10.1109 / ACCESS. 2024.3389505.
14 Beersma DGM, Stavenga DG, Kuiper JW, Organization of Visual Axes In The Compound Eye Of The Fly Musca domestica L. and behavioural consequences, J. Comp. Physiol. 102, 305 – 320( 1975). https:// doi. org / 10.1007 / BF01464343.
15 McCann GD, Arnett DW, Spectral and polarization sensitivity of the dipteran visual system, J. Gen. Physiol. 59, 534 – 558( 1972). https:// doi. org / 10.1085 / jgp. 59.5.534.
16 Tinbergen J, Stavenga DG, Photoreceptor redox state monitored in vivo by transmission and fluorescence microspectrophotometry in blowfly compound eyes, Vision Res. 26, 239 – 243,( 1986). https:// doi. org / 10.1016 / 0042-6989( 86) 90018-0.
17 Smits RP, Jansonius NM, Stavenga DG, Dependence of receptor potential and redox state of mitochondrial cytochromes on oxygen fraction measured in the blowfly eye in vivo, J. Comp. Physiol. A 177, 105 – 110( 1995). https:// doi. org / 10.1007 / BF00243402.
18 Stavenga DG, Tinbergen J, Light dependence of oxidative metabolism in fly compound eyes studied in vivo by microspectrofluorometry, Naturwissenschaften 70, 618 – 620( 1983). https:// doi. org / 10.1007 / BF00377410.
19 Stavenga DG, Colour in the eyes of insects, J. Comp. Physiol. A 188, 337 – 348( 2002). https:// doi. org / 10.1007 / s00359-002-0307-9.
20 Stavenga DG, Angular and spectral sensitivity of fly photoreceptors. III. Dependence on the pupil mechanism in the blowfly Calliphora, J. Comp. Physiol. A 190, 115 – 129( 2004). https:// doi. org / 10.1007 / s00359-003-0477-0.
