4 Conclusion
This work presented a new tooling system and established its performance for SAG finishing of narrow cylindrical optics potentially useful in optical systems. A thin wheel type finishing tool with mounting jig for an ultra-precision 7-axis finishing machine was proposed. Fluid jet finishing was also used to polish the channel surface in order to establish the need and superiority of the proposed tooling system. Fluid jet finishing fails to generate uniform surface on tungsten carbide having a binder phase. The loose abrasives in the slurry tend to remove more amount of binder material and lesser removal from the tungsten carbide grains. The proposed wheel type SAG tools with different grades of abrasive pads could produce a fine surface having roughness Ra < 3 nm. In terms of form correction, the developed tooling system could converge the P-V error on the surface with error of 18 – 35 %. There is still scope of improvement in the design and material of the wheel and jig to make it more rigid and reduce the variations in the removal rate.
Acknowledgments
The authors acknowledge support from Zeeko Ltd. in loaning the polishing and measurement equipment.
Funding This research received no external funding.
Conflicts of interest The authors have nothing to disclose.
Data availability statement
Thedatasupportingreportedresultscanbemadeavailableonreasonable request.
Author contribution statement
Conceptualization, A. P. and A. B.; Methodology, A. P. and A. B.; Software, C. J.; Validation, A. P., C. J. and A. B.; Formal Analysis, A. P.; Investigation, A. P. and C. J.; Resources, A. B.; Data Curation, A. B. andC. J.; Writing – Original Draft Preparation, A. P.; Writing – Review & Editing, C. J., A. B.; Visualization, A. P., A. B.; Supervision, A. B.; Project Administration, A. B.; Funding Acquisition, A. B.
References
1 Heald SM, Applications of bent cylindrical mirrors to X-ray beam lines, Nucl. Instrum. Methods Phys. Res. 195, 59( 1982).
2 Wang S, Kong L, Wang C, Cheung C, Ultra-precision manufacturing of microlens arrays using an optimum machining process chain, Opt Express 31, 2234( 2023).
3 Xia Z, Fang F, Ahearne E, Tao M, Advances in polishing of optical freeform surfaces: a review, J. Mater. Process. Technol. 286, 116828( 2020).
4 Beaucamp A, Namba Y, Freeman R, Dynamic multiphase modeling and optimization of fluid jet polishing process, CIRP Ann Manuf Technol 61, 315( 2012).
5 Fähnle OW, van Brug H, Frankena HJ, Fluid jet polishing of optical surfaces, Appl Opt 37, 6771( 1998).
6 Booij SM, Partosoebroto I, Braat JJM, van Brug H, Fähnle OW, in Optical Fabrication and Testing, edited by A. Sawchuk( OSA, Washington, DC, 2002). 7 Fang H, Guo P, Yu J, Surface roughness and material removal in fluid jet polishing, Appl Opt 45, 4012( 2006). 8 Beaucamp A, Katsuura T, Kawara Z, A novel ultrasonic cavitation assisted fluid jet polishing system, CIRP Annals 66, 301( 2017).
9 Chapman HN, Nugent KA, Wilkins SW, X-ray focusing using cylindrical-channel capillary arrays I theory, Appl Opt 32, 6316( 1993).
10 Beaucamp A, Namba Y, Messelink W, Walker D, Charlton P, Freeman R, Surface integrity of fluid jet polished tungsten carbide, Procedia CIRP 13, 377( 2014).
11 Zhu WL, Beaucamp A, Compliant grinding and polishing: a review, Int J Mach Tools Manuf 158, 103634( 2020).
12 Beaucamp A, Namba Y, Combrinck H, Charlton P, Freeman R, Shape adaptive grinding of CVD silicon carbide, CIRP Ann Manuf Technol 63, 317( 2014).
13 Beaucamp A, Simon P, Charlton P, King C, Matsubara A, Wegener K, Brittle-ductile transition in shape adaptive grinding( SAG) of SiC aspheric optics, Int J Mach Tools Manuf 115, 29( 2017).
14 Zhu WL, Beaucamp A, Ultra-precision finishing of low expansion ceramics by compliant abrasive technologies: a comparative study, Ceram Int 45,11527( 2019).
15 Pratap A, Yamato S, Beaucamp A, Hybrid tool combining stiff and elastic grinding. CIRP Ann 72, 281( 2023).
16 Ghosh G, Sidpara A, Bandyopadhyay A, Theoretical and experimental investigation of material removal rate in shape adaptive grinding of HVOF sprayed WC-Co coating, Precis Eng 72, 627( 2021).
17 Ke XL, Wang CJ, Guo YB, Xu Q, Modeling of tool influence function for high-efficiency polishing, Int J Adv Manuf Tech 84, 2479( 2016).
18 Wang C, Wang Z, Yang X, Sun Z, Peng Y, Guo Y, et al. Modeling of the static tool influence function of bonnet polishing based on FEA, Int J Adv Manuf Tech 74, 341( 2014).
19 Zhu WL, Yang Y, Li HN, Axinte D, Beaucamp A, Theoretical and experimental investigation of material removal mechanism in compliant shape adaptive grinding process, Int J Mach Tools Manuf 142, 76( 2019).
