Reference
The types of Ethernet standards are summarized below.
Segment
A “segment” is a unit of a LAN. It normally refers to the range of a single cable.
Type Standard
Reference
Gigabit Ethernet
“Gigabit Ethernet” is a high-speed Ethernet standard that delivers faster communication speeds of one gigabit per
second ( 1000Mbps ) . There are a
number of variations for this standard
including 1000BASE-T that uses twisted
pair cable, and 1000BASE-LX that uses
fiber optic cable.
Reference
Switch
A “switch” is a type of network device
that connects networks, and refers to a
line concentration device that houses
twisted pair cable used for 10BASE-T
and 100BASE-TX.
Fast Ethernet
“Fast Ethernet” is a high-speed Ethernet standard that delivers faster communication speeds of 100Mbps. There
are a number of variations for this
standard including 100BASE-TX that
uses twisted pair cable, and 100BASEFX that uses fiber optic cable.
Gigabit Ethernet
Fast Ethernet
Ethernet
Reference
Transmission
speed
Segment
length
Topology
Type of
cable
Connector
10
BASE5
10Mbps
500m
Bus
Coaxial
(10mm
diameter)
AUI
10
BASE2
10Mbps
185m
Bus
Lightweight
coaxial
(5mm
diameter)
BNC
10
BASE-T
10Mbps
100m
Star
Twisted
pair
RJ-45
100
BASE-TX
100Mbps
100m
Star
Twisted
pair
RJ-45
100
BASE-FX
100Mbps
2km
Star
Fiber optic DSC
1000
BASE-T
1Gbps
100m
Star
Twisted
pair
RJ-45
1000
BASE-CX
1Gbps
25m
Star
Twisted
pair
RJ-45
1000
BASE-LX
1Gbps
550m
Star
MultiDSC
mode fiber
optic
1Gbps
5km
Star
SingleDSC
mode fiber
optic
1Gbps
550m
Star
MultiDSC
mode fiber
optic
1000
BASE-SX
*1Gbps = 1000Mbps
Reference
Backbone LAN
A “backbone LAN” is a LAN for connecting multiple LANs in which computers
are directly connected, operating them
together as a single network. A backbone LAN must be fast and reliable,
and have a large capacity.
AUI
BNC
RJ-45
DSC
Reference
Types of cables
Refer to “Chapter 9-4-1 2 (3) LAN components.”
261
Application
Connect
computers
Connect
high-speed
computers
or backbone
Backbone
LAN
